液压挖掘机行走机构设计(crg)VIP免费

昆明理工大学成人高等教育毕业设计（论文）题目：液压挖掘机行走机构设计姓名：付文香专业：机电设备维修与管理年级：2010级指导教师：杜宝林函授站：昆明工业职业技术学院目录前言·····················································2-摘要·····················································2-第一章绪论··············································3-1.1液压挖掘机在现代化建设中的作用·······················3-1.2液压挖掘机的基本类型·································4-1.3本设计的目的和意义···································5-第二章总体方案设········································52.1履带式液压挖掘机的组成·······························5-2.2设计依据·············································6-2.3总体设计原则·········································7-2.4传动方式的比较与选择·································7第三章主要参数确·······································10-3.1总体几何尺寸的设计···································103.2驱动轮主要参数的确定及强度校核·······················133.3功率计及挖掘力参数计算与确定·························143.4行走装置的牵引力计算·································163.5液压马达主要参数计算确定·····························18第四章张紧装置设计要求与计算···························21-4.1张紧弹簧的设计·······································211第五章四轮一带及其他部件·······························22-5.1四轮一带选型·········································225.2悬架选型与制动器选型·································26第六章设计工作总结······································28-致谢·····················································29参考文献··················································29液压挖掘机行走机构设计【摘要】随着人类社会的不断进步，科学技术的高速发展，工程机械在各行各业中得到了很好的运用。然而，在不同的环境下，对挖掘机等工程机械的大小、性能的要求有所不同各种性能参数决定其工作环境。工程机械在国民生产中有着很重要的位置，它在很大程2度上取代了原始的、落后的生产工具，它在现今中国和全世界的飞速发展的今天功不可没。然而，在不同的环境下，对挖掘机等工程机械的大小、性能的要求有所不同，各种性能参数决定其工作环境。而挖掘机的行走装置是整个机械的支撑部分，它承受机械的自重及工作装置挖掘时的反力，使挖掘机稳定的支撑在地面工作，也是挖掘机在工作场地自由移位的装置。行走装置设计的好坏会影响挖掘机的机动性、爬坡能力、越野性能、接地比压以及挖掘机的稳定性等。【关键词】履带式，液压挖掘机，行走机构，张紧装置。前言改革开放以来，我国的科学技术、信息技术迅猛发展，各行各业都发...
