June 2006Originating Department: North American Engineering StandardsPage 1 of 4GMW15011GMWORLDWIDE ENGINEERING STANDARDSGeneral Specification ChassisAluminum Parts for Engine-Transmission Brackets and AluminumInternal Cores of Dampening Blocks1 IntroductionNote: Nothing in the specification supersedes applicable laws and regulations unless specific exemption has been obtained.Note: In the event of conflict between the English and domestic language, the English language shall take precedence.1.1Scope. Aluminum parts of the engine-transmission suspension (e.g., damping blocks, hydro mounts, hydro bushings, brackets).1.2Mission/Theme. This specification determines the requirements for aluminum parts of the engine-transmission suspension (e.g., damping blocks, hydro mounts, hydro bushings, brackets) and describes the material tests of the components.1.3Classification. Not applicable.2 ReferencesNote: Only the latest approved standards are applicable unless otherwise specified.2.1External Standards/Specifications.EN 722-2EN 755-22.2GM Standards/Specifications.GME 00150GMW3059GME 60156QN 4192GDGMW5QN4193GO3 Test Preparation and Evaluation3.1Resources.3.1.1 Calibration. The test facilities and equipment shall be in good working order and shall have a valid calibration label.3.1.2 Alternatives. Alternative test facilities and equipment may also be used. However, all measuring variables as specified in this specification shall be determined correctly with respect to its physical definition.3.1.3 Facilities. Test facilities according to references as specified in paragraph 2.3.1.4 Equipment. Not applicable.3.1.5 Test Vehicle/Test Piece. Not applicable.3.1.6 Test Time. Not applicable.3.1.7 Test Required Information. Not applicable.3.1.8 Personnel/Skills. Not applicable.3.2 P...
