buck-boost 电路的 ARM 单片机控制器的设计摘 要本文提出了一种基于 ARM 的一种新型 BUCK-BOOST(AC-AC)电路控制器设计。在斩控式 AC-AC 变换中,控制电路绝大部分还是采纳 PWM 发生模块进行模拟控制,这些模块斩波频率高,可以进行简单的 PID 控制,但也有模拟电路固有的缺点:元器件老化,温度漂移,系统不灵活,精度不高,开发速度慢等问题。本文针对于这些问题,用 ARM 嵌入式处理器 LPC2114 设计了一种新型控制器。由于 CPU 直接参加闭环控制,能显著降低系统硬件成本,同时不存在温度漂移等问题,一旦调试正常就能长期稳定运行;另外,通过软件版本改变系统功能,灵活实现复杂的控制算法。因此,随着微处理器价格的降低和技术的成熟,数字控制技术必将在高性能,智能化 DC/DC和斩控式 AC-AC 变换器中得到应用和进展。 本文对系统的结构和原理进行了具体分析,详细介绍了采纳 ARM 嵌入式处理器作为控制器的设计方法和控制策略,并进行了软件的设计,实现了 BUCK-BOOT 电路的全数字控制。关键词: ARM ,控制器,BUCK-BOOSTDesign of ARM one-chip computer controller of buck-boost circuitAbstractThis article proposed one kind based on ARM one kind of new BUCK-BOOST (AC-AC) the circuit controller design. In cuts controls type AC-AC, in the transformation, the control circuit major part uses PWM to have the module to carry on the simulation control, these modules cut the wave frequency to be high, may carry on the simple PID control, but also has the analogous circuit inherent shortcoming: the primary device aging and temperature drifting ,the system is not nimble, the precision is not high, the development speed is slow and so on. in view of this, this article design its controller with ARM Inserted type processor LPC2114, has carried on the concrete analysis to the system structure and the principle, 本模板论文目录在论文全部撰写完成后可通过链接自动生成。目录生成要求论文严格根据模板格式撰写。本模板已对各级标题与正文做好格式设置,使用此模板时只需在相应位置输入各级标题与正文,即可保证格...
