中国科技核心期刊国外电子测量技术基于ZigBee和LabVIEW的智能照明监控系统设计张世一黄华刘永平(兰州理工大学机电工程学院兰州730050)摘要:针对现有的照明控制系统大多采用有线网络、施工复杂、灵活性不够的问题,设计了一种基于ZigBee和LabVIEW技术的智能照明监控系统。系统应用ZigBee技术,以CC2530芯片做为灯控终端和网络协调器,协调器通过Z-stack协议栈组建无线网络并允许灯控终端加入,同时协调器与上位机通过RS232串口连接。利用LabVIEW软件编写上位机监控程序,程序中监控命令通过串口与协调器在灯控网络和上位机之间完成双向传递。利用少量设备为例进行了组网和监控实验,系统能够很好的完成对照明设备的开关控制和状态监测,实验结果证明了监控系统设计的可行性。关键词:ZigBee;无线通信;LabVIEW;监控软件中图分类号:TN98文献标识码:A国家标准学科分类代码:510DesignofintelligentlightingmonitoringsystembasedonZigBeeandLabVIEWZhangShiyiHuangHuaLiuYongping(SchoolofMechanical&ElectronicalEngineering,LanzhouUniversityofTechnology,Lanzhou730050,China)Abstract:Mostoftheexistinglightingcontrolsystemsarebasedonwirednetwork,theconstructionofthiskindofsys-temiscomplexandtheyarelackofflexibility.TosolvetheseproblemswehavedesignedanintelligentlightingcontrolsystemwhichisbasedonthetechnologyofZigBeeandLabVIEW.ThissystemusedthetechnologyofZigBee,thechipofCC2530wasusedforlightthenetworkcoordinatorandcontrolterminal,thewirelesscommunicationnetworkwasbu-litbycoordinatoranditallowedthelightcontrolterminaltojoinin,meanwhilethecoordinatorandmonitorPCwerelinkedthroughtheserialportofRS232.TheinterfaceofcontrolisbasedonLabVIEWtorealizethemonitoringfunction.Inthisprogram,monitoringsignalstransferedbidirectionallythroughtheserialportandcoordination.Eventually,throughaexampleofthenetworkingequipmentandmonitoringexperiment,thesystemcouldbeabetterfinishforlight-ingswitchcontrolandstatusmonitoringwhichprovedthefeasibilityofthewholesystem.Keywords:ZigBee;wirelesscommunications;LabVIEW;monitoringsoftware收稿日期:2014-011引言随着网络化自动化技术的发展,智能照明已经成为了当代一个热门的话题[1],与传统的照明技术相比,智能照明系统是节约能耗、提高物业管理水平、体现现代化生活方式与优化工作环境的有效手段。目前正在使用的智能照明系统多以有线电路为...
