毕业设计说明书中文摘要本工程是江苏省扬州市某职业学校教学行政办公楼设计,共5层,层高底层3.9米,其他层层高均为3.6米,总高18.3米,为钢筋混凝土框架结构。本框架抗震等级为二级,抗震设防烈度为7度。本说明书包括如下部分:1、工程概况;2、荷载计算;3、框架结构的受力分析、计算和设计;4、屋盖、楼盖设计;5、楼梯设计;6、基础设计。本设计包括建筑设计和结构设计,完成11张建筑施工图和7张结构施工图。结构设计主要对4轴横向框架进行了抗震设计:根据结构设计方案,采用底部剪力法求水平地震荷载作用大小,用D值法计算水平荷载作用下框架结构的内力、用弯矩二次分配法计算竖向荷载作用下的结构内力,根据内力组合找出最不利内力,对框架梁、柱进行配筋计算并绘图。此外,还进行了结构侧移验算、标准层楼盖及屋盖设计、楼梯设计和基础设计。关键词:钢筋混凝土框架结构结构设计毕业设计说明书外文摘TitleDesignoftheofficebuildingatYangzhouinJiangsuProvinceAbstract:Thisprojectisinyangzhoucity,JiangsuProvince.Thebuildingisamulti-layerreinforcedconcreteframe.Ithasfivestories,theheightofthefirststoryis3.9metersandtheothersis3.6meters.Sothewholebuildingis18.3meters.Anti-seismicgradeofthestructureis3,anditsseismicfortificationintensityis7.Thedesignincludesthefollowingcomponents:1.projectoverview;2.loadcalculation;3.Analysisoftheframestructure,includingcalculationanddesign;4.roof,floordesign;5.thestaircasedesign;6.thefoundationdesign.Thearchitecturalandstructuraldesignsofthebuildingareperformed11structuraland7architecturalshopdrawingsarefinished.Themajorpurposeofthedesignistodotheanti-seismicdesigninthelongitudinalframesofaxis4.Accordingtothestructuralscheme,thehorizontalseismicforcecanbegotbywayofthebottom-shearforcemethod.TheinternalforcesunderthehorizontalloadsareanalysiedintermsofDvaluemethodandtheinternalforcesundertheverticalloadsarecalculatedbymeansofsecondmomentdistributionmethod.Onesetofthemostadverseinternalforcesoftheframestructurearefoundoutafterinternalforcescombination,whichwillbethebasisofProtractingthereinforcingdrawingsofthecomponents.Moreover,thelateraldeformationofthestructure,thefloordesignsofthestandardlayerandtherooflayer、thestairsandthefoundationarealsobeapproachedbycalculatingandanaylsing.Keywords:reinforcedconcreteframestructurestructuraldesign目录前言.................................................................1第一章工程概况2第二章设计资料22.1地质资料22.2气象资料22.3地震资料22.4工程资料22.5结构选型.......................................................2第三章结构布置33.1结构平面布置图33.2确定框架梁柱截面尺寸3第四章荷载计算5第五章横向框架在风荷载作用下的内力和位移计算75.1横向框架在风荷载作用下的计算简图75.2横向框架在风荷载作用下的位移计算105.3横向框架在风荷载作用下的内力计算13第六章横向框架在水平地震荷载作用下的内力和位移计算176.1计算方法176.2横向框架在水平地震的位移计算186.3横向框架在水平地震作用计算206.4横向框架在水平地震荷载作用下的内力计算........................22第七章横向框架在竖向荷载作用下计算简图和内力计算...................267.1计算假定和楼面布置267.2横向框架在永久荷载作用下的计算297.3横向框架在可变荷载作用下的计算................................317.4横向框架在永久荷载作用下的内力计算............................347.5横向框架在活荷载作用下的内力计算..............................407.6横向框架在0.5(雪+活)荷载下的内力计算........................46第八章内力组合528.1弯矩调幅52第九章框架梁、柱截面设计609.1框架梁截面设计609.2框架柱截面设计65第十章楼梯结构设计计算7310.1楼梯的计算简图7310.2梯段板...
