两台9303之间起VRRP，接入层全为5352，上面起MSTP，全网路由使用OSPF。 每台5352划为一个单独的 VLAN。网络通过服务器组里的两台网关服务器提供网络接入功能。 下面发配置，大家看下这个做法什么地方有需要改进的地方。一起交流一下。 9303A dis cu # sysname Quidway # vlan batch 100 to 101 114 to 121 # stp instance 1 root primary stp enable # poe-power backup-mode 1 # dba-profile default0 type3 assure 40000 max 80000 # line-profile default0 # service-profile default0 # diffserv domain default # stp region-configuration region-name ZYDF instance 1 vlan 101 114 to 117 instance 2 vlan 118 to 121 active region-configuration # aaa authentication-scheme default authorization-scheme default accounting-scheme default domain default domain default_admin # drop-profile default # interface Vlanif100 ip address 192.168.100.78 255.255.255.0 # interface Vlanif101 ip address 192.168.3.100 255.255.255.0 vrrp vrid 1 virtual-ip 192.168.3.254 vrrp vrid 1 priority 150 vrrp vrid 11 virtual-ip 192.168.3.253 # interface Vlanif114 ip address 192.168.4.100 255.255.255.0 vrrp vrid 2 virtual-ip 192.168.4.254 vrrp vrid 2 priority 150 vrrp vrid 12 virtual-ip 192.168.4.253 # interface Vlanif115 ip address 192.168.5.100 255.255.255.0 vrrp vrid 3 virtual-ip 192.168.5.254 vrrp vrid 3 priority 150 vrrp vrid 13 virtual-ip 192.168.5.253 # interface Vlanif116 ip address 192.168.6.100 255.255.255.0 vrrp vrid 4 virtual-ip 192.168.6.254 vrrp vrid 4 priority 150 vrrp vrid 14 virtual-ip 192.168.6.253 # interface Vlanif117 ip address 192.168.7.100 255.255.255.0 vrrp vrid 5 virtual-ip 192.168.7.254 vrrp vrid 5 priority 150 vrrp vrid 15 virtual-ip 192.168.7.253 # interface Vlanif118 ip address 192.168.8.100 255.255.255.0 vrrp vrid 6 virtual-ip 192.168.8.254 vrrp vrid 6 priority 150 vrrp vrid 16 virt...
