课程设计报告智能温度测量仪专业:班级:学生姓名:学号:指导教师:完成时间:文献综述---- 智能温度测量仪摘要:本文主要介绍了智能温度测量仪的设计,包括硬件和软件的设计。 先对该测量仪进行概括性介绍,然后介绍该测量仪在硬件设计上的主要器件:“Pt100热电阻”、AT89C51单片机和 LCD显示器以及描述测量仪的总体结构原理。在本设计中,是以铂电阻 PT100作为温度传感器,采用恒流测温的方法,通过单片机进行控制,用放大器、 A/D转换器进行温度信号的采集。总体来说,该设计是切实可行的。关键词: 温度; Pt100热电阻; AT89C51单片机; LCD显示器。Abstract: This paper describes the design of the intelligent temperature measuring instrument, including hardware and software design. Be the first general description of the measuring instrument, and then describes the hardware design of the measuring instrument's main device: "Pt100 thermal resistance", AT89C51 microcontroller and LCD display, and describe the principle of measuring the overall structure. In this design, as is the PT100 platinum resistance temperature sensor, temperature measurement using constant current method, through the microcontroller to control, amplifier, A / D converter for temperature signal acquisition. Overall, the design is feasible. Key words: temperature; Pt100 thermal resistance; AT89C51 microcontroller; LCD monitor.引言: 温度是日常生活、工业、医学、环境保护、化工、石油等领域最常遇到的一个物理量, 也是工业控制中主要的被控参数之一。对温度的测量与控制在现代工业中也是运用的越来越广泛。 而传感器主要用于测量和控制系统,它的性能好坏直接影响系统的性能。 因此,不仅必须掌握各类传感器的结构、原理及其性能指标,还必须懂得传感器经过适当的接口电路调整才能满足信号的处理、显示和控制的要求,而且只有通过对传感器应用实例的原理和智能传感器实例的分析了解,才能将传感器和信息通信与信息处理结合起来,适应传感器的生产、研制、开发和应用。 另一方面, 传感器的被测信号来自于各个应用领域,每个领域都为了改革生产力、 提高工效和时效, 各自...
