ZHEJIANG WATER CONSERVANCY AND HYDROPOWERCOLLEGE毕业设计说明书题 目：红狮宝盛科技供配电设计 系 （部）： 电气系专业班级： 电力 101 姓 名：顾佳学 号：202406023 指导老师： 学虎 2024 年 4 月 20 日摘 要 工厂供电是将从电力系统中获得的电能经过合理的传输变换， 分配到工厂的 车间里的用电设备上。伴随着社会的进展，工厂对电能的质量，供电可靠性以与 经济性等要求也越来越高。工厂供电设计是否完善不仅影响工厂的生产，而且也 反映到工厂供电的可靠性与安全生产上，它与企业的经济效益，设备安全运行以 与工人的人身安全密切相关，因此，搞好工厂供电工作对于整个工厂的生产进展 有十分重要的意义。 本设计是对工厂供电一次部分的设计，对工厂的负荷计算，短路电流计算， 变电所变压器的选择，校验，无功补偿等进行了设计说明，该设计从全局出发， 根据负荷性质，用电容量等做出了合理的设计。关键词配电线路；变压器；负荷；短路电流；电气设备。ABSTRACT Power supply in factory is mean to electricity energy which is obtained fro m the power system is transferred reasonable, and it is distributed to the electric device of the factory floor. With the development of the society, the quality, re liability and economy demands of the electricity energy were increasing to the factory. Whether the design of the factory electricity supply is perfect not only affect the plant's production, but also reflects the reliability of power supply to the factor y and safety, it is closely related to the economic benefit of enterprises, equipment, safe operation and safety of workers, it is important for the development of production for doing a good job of the factory power supply work. This design is a part of power plant design, including of the plant load calculation, short circuit current calculation, and the choice of transformer substations, verification, reactive power compensation for the design specification, it make a reasonable design follow...
