MCGS 组态课程设计题 目 基于 MCGS 组态软件实现自动门设计学 号 姓 名 同 组 人 专业班级 10 级电气工程及其自动化 2 班学 院 电气工程学院 指导老师 王彩霞成 绩基于 MCGS 组态软件实现自动门设计摘要：运用 MCGS 组态软件，制作出自动门的控制画面，并编写出相应程序实现对门、灯等的控制。工作人员通过控制画面可以实时了解自动门的运行状态，及时对自动门系统故障进行报警，分析故障原因，并通过计算机直接控制自动门的运行。通过此监控，可足不出户地了解自动门的状况，大大的简化了工作员的操控流程。关键字： 自动门 MCGS 组态软件 监控 Abstract：The paper describes how the dynamic monitoring screen on HMI for the automatic door’s automated control system is designed and built by the configuration software MCGS and in module form .The staff can monitor the operational status of the door by the HM I, and give the alarm in time to solve the problems without delay if some accident happens in the automatic system .Also , the staff can control the door’s operation by PLC .It is of theoretical and practical values Key Words ： Automatic door ，MCGS software, monitor目录1绪论 ······························································41.1 立题背景 ····················································41.2 讨论问题 ····················································41.3 设计思路 ····················································42 MCGS组态主界面的设计 ··············································42.1新建工程 ····················································42.2新建用户窗口 ···········································...
