货物需求一览表及技术规格 8 -1 技术协议 1、注塑机技术规格及要求:Technical requirements 1.1 合模力:3200ton Clamping force 1.2 射出重量: 8000g/PS Shot weight 1.3 塑化能力: 200g/s plasticizing capacity 1.4 螺杆直径:140mm screw diameter 1.5 螺杆长径比:20 L/D ratio 1.6 螺杆行程: 560mm injection stroke 1.7 最大螺杆转速:110rpm Screw rpm 1.8 注射速率:1300cm3/s injection rate 1.9 射出压力: 1600kg/cm2 injection pressure 1.10 拉杆间距(H×V): 2020*1860mm Tie bar distance 1.11 模板尺寸: 3200*2900mm platen dimensions 1.12 模板最大间距: 4300mm max daylight 1.13 移模行程: 3300mm opening stroke 1.14 最大模厚: 2000mm max mold height 1.15 最小模厚:1000mm min mold height 1.16 顶出行程: 350mm ejector stroke 1.17 顶出力: 450KN ejector force 1.18 开模力:133ton opening force 1.19 注射部分:Injection Unit 1.19.1 採用雙合金料管組,並作雙螺牙設計 Bimetallic screw and barrel with double flight design 1.19.2 设备射出控制具有四段以上控制,保压控制具有四段控制。 With at least 4 stages for injection and for holding 货物需求一览表及技术规格 8 -2 1.19.3 具有熔胶前松退和熔胶后松退功能。Decompression before and after plasticizing 1.19.4 射出转保压要求有位置、时间、压力三种转换方式。Switching to holding pressure via position, time and pressure 1.19.5 油压式喷嘴可以在注射前打开 Shut off nozzle 1.19.6 喷嘴前端半径要求R24.5MM Nozzle radius R24.5 1.19.7 注 射压力 可 以 一直 持 续 或 持 续 至 保压时 间 结 束 continuous injection pressure or until holding pressure time is over 1.19.8 要求有15组程序阀功能,每个程序阀可以在循环中有5次开合功能选择(3个在注射状态,2个在保压状态),外購控制器(射膠:1開 1合;保壓:1開 1合) 15 valve gate, external control(injection: 1 open 1 close; holding pressure 1 open and 1 close) 1.19.9 开模时可以进行溶胶工作 Plasticizing on the fly 1.19.10 设 备 在 注 射座...
