磷青铜黄铜合金红铜特性及规格一览表

磷青銅 (Phosphor Bronze) 特性及規格一覽表：(1) 化學成份 ( Chemical Composition)合金編號化學成份 (wt. %) Material DesignationCu Sn p Pb Fe Zn JISC5111 C5102 C5191 Rem. Rem. Rem. ~ ~ ~ ~ ~ ~ < < < < < < < < < C5212 Rem. ~ ~ < < < (2) 物理特性 ( Physical Properties) 合金編號(Alloy No. ) 密度(Density) g/cm3彈性係數(Modulus of Elasticity) (Young’s Modulus) GPa 熱膨脹係數(Coefficient of Thermal Expansion at 20 oC to 300 oC) m/m．K 熱傳導係數(Thermal Conductivity at 20 oC) W/m．K 導電率(Electrical Conductivity at 20 oC) %IACS C5111 C5102 C5191 C5212 110 110 110 110 19 15 14 12 (3) 機械性質 ( Mechanical Properties)合金編號Alloy No. 質別Temper 符號Symbol抗拉試驗Tensile test 硬度試驗Hardness test 厚度Thickness (mm)抗拉強度Tensile strength (kgf/mm2) 延伸率 (50mm) Elongation(in 2”) (%) HvThickness >0.15mmC5111 O C5111R-O > > 30 > 38 - H/4 C5111R-H/4 > 38~45 > 28 120~150 H/2 C5111R-H/2 > 42~52 > 18 130~160 3/4H C5111R-3/4H > 48~58 > 10 150~170 H C5111R-H > 50~58 > 8 170~190 EH C5111R-EH > > 58 > 5 > 190 C5102 O C5102R-O > > 31 > 40 - H/4 C5102R-H/4 > 38~48 > 28 120~150 H/2 C5102R-H/2 > 48~58 > 18 150~170 3/4H C5102R-3/4H > 50~58 > 10 170~190 H C5102R-H > 58~68 > 8 190~210 EH C5102R-EH > > 63 > 5 > 210 Mechanical Properties (continuous) 合金編號Alloy No. 質別Temper 符號Symbol抗拉試驗Tensile test 硬度試驗Hardness test 厚度Thickness (mm)抗拉強度Tensile strength (kgf/mm2) 延伸率 (50mm) Elongation(in 2”) (%) HvThickness >0.15mm C5191 O CC5191R-O > > 32 > 42 - H/4 C5191R-H/4 > 40~52 > 35 120~150 H/2 C5191R-H/2 > 50~60 > 20 150~170 3/4H C5191R-3/4H > 52~62 > 18 170~190 H C5191R-H > 60~70 > 10 190~210 EH C5191R-EH > 65~75 > 8 210~230 SH C5191R-SH > > 75 > 5 230~270 C5212 O CC5210R-O > > 35 > 45 -...
