DINGB标准件对照表

中德标准对照表 序号 Item 德国标准 DIN-Standard 中文品名 Description in Chinese 英文品名 Desciption in English 国际标准 ISO-Standard 中国标准 GB-Standard 1 DIN1 圆锥销 Taper pins ISO2339 GB117 2 DIN7 圆柱销 Parallel pins ISO2339 GB119-86 3 DIN84 开槽圆柱头螺钉 Slotted cheese head screws ISO1207 GB65-85 4 DIN85 开槽盘头螺钉 Slotted pan head screws ISO1580 GB67-85 5 DIN93 单耳止动垫圈 Tab washers GB854 6 DIN94 开口销 Split cooter pins ISO1234 GB91 7 DIN95 开槽半沉头木螺钉 Slotted raised csk head wood screws GB101 8 DIN96 开槽半圆头木螺钉 Slotted round head wood screws GB99 9 DIN97 开槽沉头木螺钉 Slotted countersunk head wood screws GB100 10 DIN125-A 平垫 Plain washers ISO7089 GB97.1-85 11 DIN125-B 平垫（带倒角） Mediun washers ISO7090 GB97.2-85 12 DIN126 平垫 Plain washers ISO7091 13 DIN127-A 重型弹垫 Spring lock washers,tang ends GB7244 14 DIN127-B 标准弹垫 Spring lock washers,square ends GB93-87 15 DIN128-A 鞍形弹垫 Single coil spring lock washers GB7245-87 16 DIN137-A 弹簧止动垫圈 Curved spring washers 17 DIN137-B 波形弹垫 Wave spring washers GB955 18 DIN186 T 型方颈螺栓 T-head blots with square neck GB37-88 19 DIN188 T 型双接头螺栓 T-head bolts with double nip 20 DIN258 螺纹圆锥销 Taper pins with threaded end ISO8737 21 DIN261 T 型头螺栓 T-head bolts 22 DIN315AF 蝶型螺母（美制） Wing nuts America form 23 DIN315DF 蝶型螺母（德制） Wing nuts germany form GB62-88 24 DIN316AF 蝶型螺母（美制） Wing screws America form 25 DIN317DF 蝶型螺母（德制） Wing screws germany form 26 DIN319 圆球型盖型螺母 Ball knobs 27 DIN404 开槽带孔球面 圆柱头蚴钉 Slotted capstan screws GB832-88 28 DIN417 开槽长圆柱端 紧定螺钉 Slotted set srews with full dog point ISO7435 GB75-85 29 DIN427 开槽平端 紧定螺钉（半牙） Slotted set srews with chamfered e...
