HP8920A无线电综合测试仪说明书

The Agilent Technologies 8920A RF communicationtest set is a full-featured, one-box test set designedto meet the service and repair needs of today’s RFwireless communications market. Single keystroke transmitter and receiver testingsimplifies radio test. Signaling for multiple formatsis supported, including tone sequential, digital pag-ing (CCITT, POCSAG, ZVEI, etc.), DTMF, trunking,and cellular signaling. For cellular phone test, the call processing inter-face emulates a base station, allowing you to auto-matically establish and maintain a cellular linkbetween the test set and an analog cellular phone.The built-in controller allows you to automatemeasurements and test routines, and control exter-nal instruments. Combined with the Agilent 11807Asoftware, it provides a self-contained, automatedradio test solution.Key Features:•Intuitive call processing interface for cellularphone test•Functions of more than 20 complete instru-ments•Frequency ranges:Signal generator: 30 MHz to 1 GHzRF analyzer: 10 MHz to 1 GHz•Portable and lightweight•Optional full-span spectrum analyzer, trackinggenerator and adjacent channel power meter•Built-in IBASIC computerAgilent 8920ARF Communications Test SetData Sheet2Agilent 8920A RF Communications TestSet SpecificationsSpecifications describe the instrument’s warranted performanceand are valid over the entire operating/environmental rangeunless otherwise noted.Supplemental Characteristics are intended to provide additionalinformation useful in applying the instrument by giving typical, butnon-warranted performance parameters. These characteristics areshown in italics or labeled as “typical,” “usable to,” or “nominal.”Signal Generator Specifications RF FrequencyFrequency Range:Standard: 30 MHz to 1 GHzOption 055: 250...
