仪表电缆外径及重量计算

① DJYVP DJYVP2 DJYVP3 型结构尺寸 标称截面 (MM²) 线径结构 根数/线径 (mm) 最大外径(mm) 近似重量(kg/km) DJYVP DJYVP2 DJYVP3 DJYVP DJYVP2 DJYVP3 1× 2× 0.5 1× 2× 0.75 1× 2× 1.0 1× 2× 1.5 1/0.80 1/0.97 1/1.13 1/1.38 7.6 8.2 8.8 9.5 7.3 7.8 8.5 9.2 9.6 10.0 10.6 11.3 65 71 81 100 47 52 61 78 83 90 103 124 1× 2× 2.5 2× 2× 0.5 2× 2× 0.75 2× 2× 1.0 1/1.78 1/0.8 1/0.97 1/1.13 10.5 10.5 11.2 12.6 10.2 10.0 10.7 12.1 12.3 12.5 13.2 14.6 132 109 134 158 109 84 106 129 164 139 165 196 2× 2× 1.5 2× 2× 2.5 3× 2× 0.5 3× 2× 0.75 3× 2× 1.0 1/1.38 1/1.78 1/0.80 1/0.97 1/1.13 13.8 16.2 11.0 12.2 13.7 13.3 15.7 10.5 11.7 13.2 15.8 18.2 13.0 14.2 15.7 244 270 132 169 196 211 243 105 139 165 284 343 163 202 236 3× 2× 1.5 3× 2× 2.5 4× 2× 0.5 4× 2× 0.75 1/1.38 1/1.78 1/0.8 1/0.97 15.0 17.2 11.8 12.7 14.5 16.7 11.3 12.2 17.0 19.2 12.8 14.7 249 347 165 206 214 308 135 173 303 415 199 242 4× 2× 1.0 4× 2× 1.5 4× 2× 2.5 5× 2× 0.5 1/1.13 1/1.38 1/1.78 1/0.80 14.4 15.7 18.7 13.0 14.0 15.0 18.2 12.5 16.4 17.7 20.9 15.0 249 310 462 194 206 272 400 162 295 370 518 233 5× 2× 0.75 5× 2× 1.0 5× 2× 1.5 5× 2× 2.5 1/0.97 1/1.13 1/1.38 1/1.78 14.0 16.0 17.5 20.9 13.5 15.5 17.0 20.4 16.0 18.0 19.5 23.0 247 288 384 564 212 250 341 496 299 349 449 627 7× 2× 0.75 7× 2× 0.75 7× 2× 1.0 7× 2× 1.5 1/0.8 1/0.97 1/1.13 1/1.38 13.8 15.3 17.4 19.0 13.3 14.8 17.0 18.5 15.8 17.3 19.5 21.2 242 310 375 512 207 272 333 448 296 368 441 566 7×2×2.5 8×2×0.5 8×2×0.75 8×2×1.0 1/1.78 1/0.80 1/0.97 1/1.13 22.7 15.3 16.8 19.2 22.2 14.8 16.3 18.7 25.0 17.3 18.8 21.5 728 277 367 455 654 240 325 382 798 336 429 499 8×2×1.5 8×2×2...
