毕业论文(设计) 基于单片机的数字测速设计 院 系 航空电子电气工程系 专 业 应用电子 班 级 电子 1102 学 号 姓 名 指导老师 二 Ο 一四年 六 月 三 日诚 信 声 明本人郑重声明:所呈交的大专毕业论文(设计),是本人在指导老师的指导下,独立进行讨论所取得的成果。尽我所知,除了设计(论文)中特别加以标注和致谢的地方外,论文中不包含其他人已经发表或撰写过的讨论成果。本人完全意识到本声明的法律结果由本人承担。 毕业论文(设计)作者签名:王三喜 20014 年 6 月 3 日基于单片机的数字测速设计摘 要 随着科技的迅速进展,单片机的应用也越来越广泛,并带动传统控制检测技术不断更新。现在的车速表大多是电子式的,用 LED 数码管或 LCD 即时显示,显示更加直观。本文介绍了霍尔传感器测速的原理,设计基于单片机 AT89C51 的电动车转速测量系统。完成了转速测量系统的硬件电路设计、霍尔传感器测量电路的设计、显示电路的设计。测量转速的霍尔传感器和机轴同轴连接,定时器计数时间,即可实现对电动车转速的测量。在显示电路设计中,通过数码光直观地显示电机的转速值。并对电动车转速测量系统的硬件电路、显示电路进行了调试,与软件配合,实现了显示速度和里程。仿真实验表明所设计的硬件电路及软件程序是正确的,满足设计要求。关键词:转速测量;霍尔传感器;单片机;AT89C51Abstract With the rapid development of technology, more and more widespread application of microcomputer, and promote the traditional control detection technology update. Now the speed table is mostly electronic, use LED digital tube or LCD display real-time, display more intuitive. This paper introduces the principle of Holzer velocity measurement system design of the sensor, electric vehicle speed based on AT89C51. Completion of the speed measurement system hardware circuit design, the Holzer sensor measurement circuit design, display circuit design. Measure the speed of Holzer sensor and shaft coaxial connection, the timer count time, can realize the measurement of the electric vehicle speed. In the design of display circuit, the...
