第1页共7页编号：时间：2021年x月x日书山有路勤为径，学海无涯苦作舟页码：第1页共7页真空吸尘器翻倒测试（人体支撑式）修订日期修订单号修订内容摘要页次版次修订审核批准2011/03/30/系统文件新制定2A/0///第2页共7页第1页共7页编号：时间：2021年x月x日书山有路勤为径，学海无涯苦作舟页码：第2页共7页批准：审核：编制：真空吸尘器翻倒测试（人体支撑式）1.0Purpose/目的Toevaluatethesafetyofthebodysupportedtypesamplewhentipoveredwithcontainerfilledtomaximumcapacity评估人体支撑式吸湿型样機在吸满水后在翻倒过程中是否符合UL1017安全要求2.0Definition/概念:None無.3.0ReferenceDocuments/參考文獻:U.L.1017CAN/CSA-C22.2NO.243-01,dated12-7-2001,CL5.12.6.2，5.12.6.4,5.12.6.5&5.12.6.64.0Equipment/設備:4.1LeakageCurrentTester.泄漏电流測試儀.第3页共7页第2页共7页编号：时间：2021年x月x日书山有路勤为径，学海无涯苦作舟页码：第3页共7页4.2Leakagetestswitchingbox.泄漏电流测试盒4.3FrequencyConverter.变频电源4.4Stopwatch.秒表4.5WithstandingVoltageTester耐压测试仪4.6Testvessel测试容器5.0GeneralInstructions/說明:5.1Testsmaybeconductedatanyambienttemperaturewithinarangeof10-40(50-100).℃℉測試可在10~40(50~100)℃℉之內的環境溫度下進行.5.2Unlessotherwisenoted,alltestsaretobeconductedwithapplianceconnectedtoa120VAC,60Hzpowersource.除非另外標注,否則所有样機都将连接在120V/60Hz電源下进行測試.5.3Allequipmentusedmustbecalibratedonanannualbasis.Calibrationstickerswithlastcalibrationandcalibrationduedatemustbeaffixedtoeachinstrument..使用的所有設備都必須以一年為周期進行調校.載有最後調校日期和調校周的調校粘紙必須被粘固在每個儀表上.5.4Inthistest,recordleakagecurrentaccordingtothemethodnotedinTAREGW1004.本测试中，按照TAREGW1004所述记录测试前，中，后的泄漏电第4页共7页第3页共7页编号：时间：2021年x月x日书山有路勤为径，学海无涯苦作舟页码：第4页共7页流.5.5Forthistest,thesampleandvesselmustbeisolatedfromground.测试过程中，测试容器要与地绝缘.6.0Procedure/步驟:6.1Obtainarepresentativesampleoftheappliancetobetested.準備一台有代表性的樣機用於測試6.2ObtainTestResultsFormTTR1039andcompletelyfillintheinformationdescribingthesampleandtheequipmentusedpriortorunningthetest.用TTR1039測試結果的表格,在測試運作前完整地填入樣機和使用的設備的情況.6.3Connectthesample,LeakageCurrentTester&LeakagetestingswitchboxtogetherperTAREGW1004.按照TAREGW1004所述将样機，泄漏电流測試儀，泄漏电流测试盒等连接好电源.6.4Defeatthefloat.使浮子失效6.5Operatethesamplecontinuouslypickingupwateruntilthecontainerisfilledtomaximumcapacity.Thende-energized(butnotunplugged,withtheLeakagetestswitchingboxSW1open)andtipoverthesamplefor30seconds.Thetipoveristoconsistofplacingthesampletorestonitsside(approximately90第5页共7页第4页共7页编号：时间：2021年x月x日书山有路勤为径，学海无涯苦作舟页码：第5页共7页degrees).Thenreturnittoitsuprightpositionandenergizeditfor30secondsdrawingaironly.Thisprocedureoffillingtocapacity,tippingover,anduprightistoberepeatedforatotaloffourtimes,tippinginadifferentdirectioneachtime运行样機直到吸满水，让SW1处于“OFF”位使样機不通电，把样機翻倒至其一侧（与其直立时呈近90°）30秒，再恢复样機至直立位状态通电运行吸空气30秒。将这个吸满水，翻倒，直立吸气步骤共重复四次，每次翻倒位置要不同.6.6Wipeuptheenclosureofthesamplecarefullyandperformdielectricvoltage-withstandtestonitperthemethodnotedinTAREGW1007.抺干样機外壳表面水迹，按照TAREGW1007做耐压测试.6.7Disassemblethesamplewithgreatcareandcheckfortheevidenceofwettingofuninsulatedliveparts.小心拆开样機检查内部水迹状况6.8Repeat...
