第1页共6页编号：时间：2021年x月x日书山有路勤为径，学海无涯苦作舟页码：第1页共6页外文文献资料Generalall-steelpunchingdie’spunchingaccuracyGeneralall-steelpunchingdie’spunchingaccuracyAccuracyofpanelpunchingpartisdisplaythepressaccuracyofthedieexactly.Buttheaccuracyofanypunchingparts’lineardimensionandpositionalaccuracyalmostdependontheblankingandblankingaccuracy,.Sothatthecompoundmouldofcompoundpunching’saccuracy,istypicalnessandrepresentationinthemajority.Analyseofthedie’saccuracyFortheanalyseofpracyicableinaccuracyduringproductionofdiestoinactivation,wecouldgetthetendencywhenitisaugmentationinmosttime.Fromthiswecouldanalysetheelements.Whenthenewpunchdiesptintoproductiontothefirstcuttergrinding,theinaccuracyproducedcalledinitialerror;ifthediegrindingmorethantwentytimes,untilit’sdiscard,theinaccuracycalledconventionalerror;andbeforethediesdiscard,thelargesterrorofthelastbatchpermit,calledlimitingerror.atjobsite,theevidencetoconfirmlifeofsharpeningisthehigheroftheblanking,punchedholeorpunchedparts.Becauseallfinishedpartshadbeenblanked,soitisespeciallyforthecompounddies.Therefore,theanalyseofburrandmeasurementisespeciallyimportantwhendothemasenterprisestandardizationorcheckedwith<>.Theinitialerrorusuallyistheminimalthroughthewholelifeofdie.Itsmagnitudedependontheaccuracyofmanufacture,quality,measureofthepunchingpart,thicknessofpanel,magnitudeofgapanddegreeofhomogeneity.Theaccuracyofmanufacturedependonthemanufactureprocess.Forthe1mmthickedcompoundpunchingpartmadeinmediumsteel,theexperimentalresultandproductivepracticeallprovethattheburrofdieswhichproducedbysparkcuttingarehigher25%~~30%thanproducedbygrinder,NCorCNC.ThereasonisthatnotonlythelatterhavemoreexactmachiningaccuracybutalsothevalueofroughnessRaislessoneorderthantheformmer,itcanbereached0.025μm.Therefore,thedie’sinitialblankedaccuracydependsontheaccuracyofmanufacture,qualityandsoon.第2页共6页第1页共6页编号：时间：2021年x月x日书山有路勤为径，学海无涯苦作舟页码：第2页共6页Thenormalerrorofthepunchdieisthepracticableerrorwhenthefistcuttergrindingandthelastcuttergrindingbeforethedieproducethelastqualifiedproduct.Astheincreaseofcuttergrinding,causedthemeasurethenaturewearofthediesaregradualincreasing,theerrorofpunchingpartincreasealso,sothepartsareblewproof.Andthediewillbeunused.Theholeonthepartandinnerbecausethemeasureofwearwillbesmallandsmallgradually,anditsoutsideformwillbelagerinthesamereason.Therefore,theholeandinnerforminthepartwillbemademouldaccordingtoone-waypositivedeviationornearlyequaltothelimitmaxmeasure.Inlikemanner,thepunchingpart’sappearancewillbemademouldaccordingtoone-waynegativedeviationornearlyequaltolimitminimeasure.Forthiswillbebroadenthenormalerror,andthecuttergrindingtimeswillbeincreased,thelifewillbelong.Thelimiterrorinpunchingpartsarethemaxdimensionerrorwhichpracticableallowedinthepartswithlimiterror.Thiskindofpartsusuallyarethelastqualifiedproductsbeforethediediscard.Fortheallclassesofdies,ifweanalysethefluctuate,tendencyofincreaseanddecreaseandlawwhichappearedinthedie’swholelife,wewillfindthatthemasteroftheerrorarechangeless;theerrorthatbecausetheabradeofthecutterandimpressionwillbeasthecuttergrindingtimesincreasedatthesametime.Andthatwillcausetheerroroversizegradually;andalsohaveanotherparterrorareunconventional,unforeseen.Therefore,everydie’serrorarecomposedo...
