第24卷�第3期2010年6月现�代�地�质GEOSCIENCEVol�24�No�3Jun�2010南海神狐海域含水合物地层测井响应特征梁�劲1,2,王明君3,陆敬安2,王宏斌2,梁金强2,苏丕波4(1�中国地质大学地球物理与空间信息学院,湖北武汉�430074;2�广州海洋地质调查局,广东广州�510760;3�中国地质科学院矿产资源研究所,北京�100037;4�厦门大学海洋与环境学院,福建厦门�361005)��收稿日期:2010�02�26;改回日期:2010�05�04;责任编辑:潘令枝。��基金项目:中国科学院边缘海地质重点实验室项目(MSGL08-03);国家重点基础研究发展计划(2009CB219508)。��作者简介:梁�劲,男,高级工程师,1971年出生,应用地球物理专业,主要从事天然气水合物调查与研究工作。Emai:lliangjin1999@163�com。摘要:分析了南海北部神狐海域含天然气水合物沉积层声波速度及密度的分布特征和变化规律,并通过对比DSDP84航次570号钻孔含天然气水合物层段测井资料,总结出神狐海域含水合物地层的测井响应规律特征:神狐海域含水合物地层存在着明显的高声波速度、低密度特征,地层密度随声波速度的变化并不是单一的反比例关系,总体趋势上随声波速度的升高而降低;含水合物地层高声波速度值主要集中在197~220m段,饱和度值在15%~47%之间,低密度值集中在200~212m段,分布在水合物饱和度大于20%的地层内;含水合物地层声波速度平均值为2076m/s,其上覆和下伏地层的声波速度平均值为1903m/s和1892m/s,所对应的地层密度值分别为1�89g/cm3、1�98g/cm3和2�03g/cm3,声波速度受孔隙度和饱和度的共同影响,地层密度受水合物饱和度影响较大;从水合物上覆地层到声波速度最高值段,声波速度值增加了9�1%,相对应的地层密度值减少了4�55%,从水合物声波速度最高值段到下伏地层,声波速度值减少了8�86%,相对应的地层密度值增加了7�41%。这些测井响应特征,可用来识别地层中天然气水合物,并可以用来计算水合物的饱和度,同时结合其他地质和地球物理资料,确定水合物层的厚度、分布范围,计算天然气水合物的资源量。关键词:水合物;测井响应;速度;密度;孔隙度;饱和度中图分类号:P631�8����文献标志码:A����文章编号:1000-8527(2010)03-0506-09LoggingResponseCharacteristicsofGasHydrateFormationinShenhuAreaoftheSouthChinaSeaLIANGJin1,2,WANGMing�jun3,LUJing�an2,WANGHong�bin2,LIANGJin�qiang2,SUPi�bo4(1�CollegeofGeophysicsandSpaceInformation,ChinaUniversityofGeosciences,Wuhan,Hubei�430074,China;2�GuangzhouMarineGeologicalSurvey,Guangzhou,Guangdong�510760,China;3�InstituteofMineralResources,ChineseAcademyofGeologicalSciences,Beijing�100037,China;4�CollegeofOceanographyandEnvironmentalScience,XiamenUniversity,Xiamen,Fujian�361005,China)Abstract:Withanalysisofthedistributingfeatureandthechanginglawofthesonicvelocityanddensityofsedi�mentswithgashydrateinShenhuAreaoftheSouthChinaSea,bycomparingwithloggingdataofgashydrateformationatSite570ofDSDP84,theloggingresponsecharacteristicsofgashydrateformationinShenhuAreawereconducted.Theresultsshowtha:t(1)SedimentswithgashydrateinShenhuAreahavetheclearfeaturesthatthesonicvelocityishighanddensityislow,andthedensityisgenerallydecreasedwiththeincreasingofthesonicvelocity.(2)Thehighsonicvelocitysectioninsedimentswithgashydrateisinthedepthof197to220m,andthelowdensitysectionisinthedepthof200to212m;thevalueofsaturationisintherangeof15%to47%.(3)Theaveragesonicvelocitiesofsedimentswithgashydratesandtheoverlyingstrataandun�derlyingstrataare2,076m/s,1,903m/sand1,892m/s,respectively,andthecorrespondingdensitiesare1�89g/cm3,1�98g/cm3and2�03g/cm3,respectively;sonicvelocityiseffectedbyporosityandsaturation,anddensityisgreatlyinfluencedbysaturation;(4)Thesonicvelocityincreasesby9�1%fromtheoverlyingstrataofhydratestothemaximum�valuesection,andthecorresponding...
