15000m3/h风量双源型全新风除湿机设计报告书南京五洲制冷集团有限公司二零一零年八月目录1.设计要求..........................................................................................................................................................-1-2.空气处理过程..................................................................................................................................................-1-3.设计计算..........................................................................................................................................................-3-3.1进风状态参数...........................................................................................................................................-3-3.2热管换热器设计.......................................................................................................................................-3-3.3表冷器设计..............................................................................................................................................-4-3.4冷冻除湿各元件的设计..........................................................................................................................-5-3.5机组最低出风参数的校核.......................................................................................................................-8-3.6最大补水量的计算...................................................................................................................................-9-3.7确定风口尺寸及风机的选配...................................................................................................................-9-4.其他季节工况下机组的校核计算................................................................................................................-10-4.1夏季最恶劣工况.....................................................................................................................................-10-4.2过渡季节工况.........................................................................................................................................-12-4.3冬季工况.................................................................................................................................................-13-5.机组框架和面板机械强度校核....................................................................................................................-13-6.技术参数表....................................................................................................................................................-14-7.配置清单......................................................................................................................................................-15-8成本核算........................................................................................................................................................-16-15000m3/h风量双源型全新风除湿机设计报告书1.设计要求（1）夏季室外计算工况为DB33℃/WB27℃；（2）高温冷冻水供回水温度为15/20℃；（3）工作电源：AC380V/3P/50Hz；（4）机组夏季设计送风含湿量不高于8g/kg干；（5）机组夏季送风温度在16~22℃之间可调；（6）机组运行补水由自来水提供；（7）送风量：V1=15000m3/h；（8）回风量：V2=12000m3/h2.空气处理过程由设计边界条件可知：夏季进风工况：DB33℃/WB27℃，焓值为84.9kJ/kg，含湿量为20.1g/kg·干；要求出...
