REE-SX470/471/472/473/474/670/671/672/673/674(P)Photomicrosensor with 50 mA (PNP) or100 mA (NPN) Switching Capacity thatcan be Built into EquipmentH Standard, L-shaped, T-shaped, and closemounting models availableH Easy to maintain, plugs into Connectorcordset EE-1006H Models available with Light-ON orLight-ON/Dark-ON output configurationsH Response frequency as high as 1 kHzH Easy operation monitoring with bright LEDindicatorH Wide operating voltage range (5 to24 VDC) makes smooth connection of thephotomicrosensor with TTLs, relays, andprogrammable controllers (PLC) possibleOrdering InformationAppearanceSensing methodSlot widthSlot depthOutput configurationWeightPart nu mberStandardSlot5 mm9 mmLight-ONApprox.EE-SX470gpp3.1 gEE-SX470PLight-ON/Dark-ON(St )EE-SX670g/(See note)EE-SX670PL-shapedLight-ONApprox.EE-SX471pgpp3.0 gEE-SX471PLight-ON/Dark-ON(St )EE-SX671g/(See note)EE-SX671PT-shapedLight-ONApprox.EE-SX472pgpp2.4 gEE-SX472PLight-ON/Dark-ON(St )EE-SX672g/(See note)EE-SX672PClose-mountingLight-ONApprox.EE-SX473ggpp2.3 gEE-SX473PLight-ON/Dark-ON(St )EE-SX673g/(See note)EE-SX673PClose-mountingLight-ONApprox.EE-SX474ggpp3.0 gEE-SX474PLight-ON/Dark-ONEE-SX674gEE-SX674PNote: The EE-SX67j series models can be used as Light-ON models when the L terminal and positive (+) terminal are short-circuited.To use them as Dark-ONmodelsdo not short-circuit these terminals. Connector EE-1001-1 can be used for Light-ON operation.EE-SX470/471/472/473/474/670/671/672/673/674(P)EE-SX470/471/472/473/474/670/671/672/673/674(P)2J ACCESSORIESNamePart nu mberSolder connectorEE-1001Connector with 2 m cableEE-1006Connector holder for EE-1006EE-1006ASpecificationsJ RATINGSItemStandardL-shapedT-shapedClose-mountingOutput typeNPNoutputEE-SX470EE-SX670EE-SX471EE-SX671EE-SX472EE-SX672EE-SX473, EE-SX474EE-SX673, EE-SX674PNPoutputEE-SX470PEE-SX670PEE-SX471PE...
