ENGLISH中国語ENGLISH中国語1body刀体1055chamfer width倒角宽度2shank刀柄1056width切入齿宽3cutting part切削部分1057height切入齿高4tip刀片1058hole diameter孔径5indexable insert可转位刀片1059recess退刀槽6blade焊接刀片1060bearing支承面7neck颈部1061bearing length支承面长度8flute容屑槽1062keyway键槽9heel刀背与槽的交线(第二副后面)1063tenon端面键槽10back taper倒锥1064body刀体11face前刀面1065shank柄12flank后刀面1066blade刀片13major flank主后面1067segment扇形块14minor flank副后面1068tip刀片15land刃背1069hub台肩16margin棱边1070hub diameter台户直径17cutting edge切削刃1071hub length台肩长度18condition of cutting edge切削刃条件1072hub face台肩端面19major cutting edge主切削刃1073width across flats of hub台肩削平的厚度20 minor cutting edge副切削刃1074clamp face安装面21side cutting edge主切削刃1075counter bore diameter沉孔直径22 end cutting edge副切削刃1076depth of counter bore沉孔深度23 cutting edge roundness切削刃圆角1077datum clamp face基准安装面24 corner刀尖1078bottom face齿底面25 rounded corner修圆刀尖1079datum end face基准端面26 corner radius刀尖圆弧半径rε1080right face安装面(刨齿刀切削刃面)27 chamfered corner倒角刀尖1081reverse face反面(刨齿刀切削刃反28 chip pocket容屑槽1082end face端面29 chip former卷屑槽1083side face侧面30 chip breaker断屑槽1084cutting tooth切削齿31leading part导锥1085cutting edge切削刃32 reference systems参考系1086right cutting edge右切削刃33 tool-in-hand system刀具静止参考系1087left cutting edge左切削刃34 tool-in-use system刀具工作参考系1088top cutting edge顶刃35 reference plane参考平面Pr1089face前面36 v-axis主运动方向轴1090tooth flank齿侧面37 f-axis进给运动方向轴1091right tooth flank右侧齿面38 p-axis切削运动方向轴1092left tooth flank左侧齿面39 o-axis正交轴1093flank后面40 s-axis主切削刃轴1094top齿顶41n-axis法向轴1095bottom齿底42 working plane工作平面Pf1096top land齿顶面43 back plane工作背平面Pp1097bottom land齿底面44 cutting edge plane切削平面Ps1098width of...
