J403.K (08/12)1pu lseelectronics.comPulseJack™1x1 Tab-DOWN RJ45RoHS peak wave solder temperature rating 260°CSuitable for CAT 5 & 6 Fast Ethernet Cable or better UTPMeets or exceeds IEEE 802.3 standard for 100Base-TX350 µH minimum OCL with 8mA bias currentMinimum 1500Vrms isolation per IEEE 802.3 requirementUSA 858 674 8100Germany 49 7032 7806 0Singapore 65 6287 8998Shanghai 86 21 62787060China 86 755 33966678Taiwan 886 3 4356768Features and Benefits:Electrical Performance Summary: Mating Force Unmating Force Plug to Jack Part Number (MAX) (MAX) Durability Retention (MIN) J0 Series 5 lbs./2.268 kgs. 5 lbs./2.268 kgs. 750 Insertions 20 lbs./9.072 kgs.RJ45 Durability Testing Rating Part Shield Contact Housing MSL 3 Number Material Finish Material Plating Area Solder Area 2 Material Specification Rating J0 10-20m inches Nickel over Phosphor Nickel underplating and 120µ inches SN100 Series Brass 10-20m inches Brass Bronze selective gold plating 15µ inches over 50µ inches nickel Thermoplastic UL 94 V-0 1RJ45 Material SpecificationElectrical Specifications @ 25°C — Operating Temperature 0°C to +70°C Insertion Return Loss Common Mode RoHS Compliant Turns Mech. EMI LEDs1 Loss (dB TYP) Crosstalk Rejection Hipot Part Number Ratios Drawing Fingers (L/R) (dB TYP) 100W ±15W (dB TYP) (dB TYP) (VDC) TX RX 1-65 1-10 10-30 30-60 60-80 1-30 30-60 60-100 1-50 50-150 MHz MHz MHz MHz MHz MHz MHz MHz MHz MHz 1 MIN J0006D01BNL 1CT:1 1CT:1 A No G/Y -1 -20 -16 -12 -10 -40 -35 -30 -30 -20 2250J0006D21NL 1CT:1 1CT:1 D YES N/A -1 -20 -16 -12 -10 -40 -35 -30 -30 -20 2250J0006D21BNL 1CT:1 1CT:1 B YES G/Y -1 -20 -16 -12 -10 -40 -35 -30 -30 -20 2250J0011D01NL 1CT:1 1CT:1 C No N/A -1 -20 -16 -12 -10 -40 -35 -30 -30...
