2 0 1 0SHANGHAI BANGPU INDUSTRIAL GROUP CO.,LTD.XBD SERIES SINGLE-STAGE SINGLE-SUCTION FIRE-FIGHTING PUMP04XBD series atlas of style05XBD series centrifugal pump catalogue08property curve, performance data and installing dimension figure&tableInstallation methods for XBD-BPL series pump6870XBD-BPL series pump spare parts and installation basic figure&tableInstallation basic figure&table for XBD-BPL series pump non-isolation7274XBD-SLW series pump installation basic figure&table03XBD The structure of XBD type pump01 Outline01 Purpose01Specification range02Model meaning 02Structural featuresOUTLINE XBD()()ISO2858GB6245 GB6245 XBD series single-stage single-suction vertical( horizon-tai)fixed-type fire-fighting pump unit (pump) is a brand-new p-roduct designed and produced by this Co.upon the demand of industrial and mineral enterprises, engineering constructi on an d hi gh buildings for fire-fighting and strictly according to the international standard ISO2858 and the latest national standard GB6245, f ire-f ighting pumps . The product is approved, with its sealed sample tested by the national fire-fighting equipment quality super vising & testing centre, f ully conf orming the requirements in GB6245and its perf ormance reaches the advanced level of the same d-omestic ones.PURPOSE XBD80 () XBD()() Suitable to transport the liquid below 80containing no solid grains or both physical and chemical natures of whi-ch are similar to those of pure water and the slightly corrosive liquid. This series pump is mainly used for the water supply for the fixed fire-fighting system in both industrial and civil bui-ldings (fire hydrant extinguishing system, auto-spraying exti-nguishing system, water-fog spraying extinguishing system etc.) The performance ...
