基于光伏发电的UPS双向逆变器控制策略的研究应用分析

下载后可任意编辑基 于 光 伏 发 电 的 UPS 双 向 逆 变 器 控制 策 略 的 讨 论司 莎 莎 ， 郑 加 ， 崔 昊 辰（安徽理工大学，安徽 淮南 232001）摘要：提出了一种带有光伏发电的UPS 系统，阐述了该系统的结构图。在分析双向变换器的拓扑结构、工作原理的基础上，采纳基于前馈解耦控制的双环控制策略，实现整流逆变不同模式的自动切换以达到能量双向流动的目的。该方法具有输入电流无静差跟踪，对电网谐波污染少、功率因数高等优点。关键词：带有光伏发电的UPS ；双向逆变器；前馈解耦中图分类号：TM464 文献标识码：A 文章编号：1001-1390 （2024）00-0000-00Research on the Control Strategy of Photovoltaic Power Generation based UPSPV UPS with Bi-directional Inverter Control Strategy SI Sha-sha, ZHENG Jia, CUI Hao-chen（Anhui University of Science & Technology, Huainan 232001, Anhui, China ）Abstract: This paper presents aA UPS system with PV photovoltaic power generation has been proposed in this paper andto explain the structure of the system has been stated in detail. In On the basis of analyzing the bidirectional converter topology, and working principle, based on thea feedforward decoupling based double loop feedforward control loop control strategy has been adopted to achieve the automatic switch in different modes of rectifier inverter automatically switches as so to to achieve a energy bi-direction flow.achieve the purpose of energy flow in both directions. This method hasThere is not any no static error tracking input current, and the harmonic pollution is low as well as, the power factor advantagesis high.. Key words: with a photovoltaic power generation UPS, bi-directional inverter ,feedforward decoupling0 引 言 在传统并网型光伏发电系统中，蓄电池与电网通过双向逆变器连接，光伏电池阵列通过整流器与电网连接。本文设计讨论了一种带有光伏发电的UPS 系统，这种系统用在线互动式UPS 来连接电网与光伏发电系统，用双向...
