HD700系列通用变频器

电气设计及维修必备资料主编：冯项羽55HD700 系列通用变频器（0.4kW～500kW)第一章、技术规格1.1 型号命名规则图 1-1HD700 变频器型号说明1.2 铭牌图例图 1-2HD700 变频器单功率机型铭牌示例图 1-3HD700 变频器双功率机型铭牌示例注：SizeA、B、C 都是单机型，SizeD 及以上机型为 G/P 合一机型。1.3功率等级本节所述功率等级规格针对标准四极三相交流异步电动机而给出。G、E：恒转矩负载P：风机、泵类负载G、E型机过载能力：150%额定输出电流1分钟；P型机过载能力：110%额定输出电流1分钟。表 1-1220V 电压等级产品功率规格主电源等级：220V，50Hz，单/三相变频器型号默认载频（kHz）额定容量（kVA）输入电流单相/三相（A）额定输出电流（A）适配电机功率（kW）箱体规格HD700-20D0004061.17.1/42.80.4AHD700-20D0007561.912.8/7.150.75AHD700-20D0015063.020.5/11.381.5AHD700-20D0022064.224/14.5112.2BHD700-20D0040066.716.517.64C电气设计及维修必备资料主编：冯项羽56表1-2380V 电压等级产品功率规格主电源等级：380V，50Hz，三相变频器型号默认载频（kHz）G 型P 型箱体规格额定容量(kVA)输入电流(A)额定输出电流(A)适配电机功率(kW)额定容量(kVA)输入电流(A)额定输出电流(A)适配电机功率(kW)HD700-40T0007561.73.62.50.75−−−−AHD700-40T0015062.85.74.21.5−−−−AHD700-40T00220E63.46.15.22.2AHD700-40T0022063.88.35.82.2−−−−BHD700-40T0040066.313.29.53.7−−−−BHD700-40T00550E68.614.3135.5−−−−BHD700-40T00550P6−−−−8.614.3135.5BHD700-40T0055068.612.4135.5−−−−CHD700-40T0075061116.1177.5−−−−CHD700-40T01100P6−−−−15.2212311CHD700-40T01100616.524251121313215DHD700-40T0150062131321525363818.5DHD700-40T01850625363818.530444622EHD700-40T0220063044462240586030EHD700-40T03000E34058603050727537E1HD700-40T03700E350727537−−−−E1HD700-40T0300034058603050727537FHD700-40T0370035072753763939645FHD700-40T045003639396458312112555FHD700-40T055003831211255510315115675FHD700-40T0750031031511567511917518090FHD700-40T09000311917518090139204210110GHD700-40T110003139204210110169248256132GHD700-40T132003169248256132205301310160GHD700-40T16000E3205301310160231340350185JHD700-40T18500E3231340350185255375387200JHD700-40T20000E3255375387200...
