华为nat配置实例

窗体顶端 NAT 【Router】 当前路由器提示视图 依次输入的配置命令，重要的命令红色突出显示 简单说明 [Quidway] acl number 2000 [Quidway-acl-basic-2000] rule permit source 10.124.187.0 0.0.0.255 配置允许进行NAT转换的内网地址段 [Quidway-acl-basic-2000] rule deny [Quidway] interface Ethernet0/1 [Quidway-Ethernet0/1] ip address 10.124.187.1 255.0.0.0 内网网关 [Quidway] interface Ethernet0/0 [Quidway-Ethernet0/1] ip address 10.124.1.1 255.255.255.248 [Quidway-Ethernet0/1] nat outbound 2000 在出接口上进行 NAT转换 [Quidway] ip route-static 0.0.0.0 0.0.0.0 101.1.1.1 preference 60 配置默认路由 华为路由器单臂路由配置实例 组网描述: PC---------------------3050C-------------------------AR28-31-------------------------INTERNET 组网实现: 3050C上划分多个 VLAN,在 AR28-31上终结 VLAN信息,下面的所有 VLAN中的 PC都可以上公网,所有的PC机都通过AR28-31分配IP地址和DNS [AR28-31]dis cu # sysname Quidway # FTP server enable # nat address-group 0 222.222.222.2 222.222.222.10 用于上公网的地址池 # radius scheme system # domain system # local-user admin password cipher .]@USE=B,53Q=^Q`MAF4<1!! service-type telnet terminal level 3 service-type ftp local-user huawei telnet用户,用于远程管理 password simple huawei service-type telnet level 3 # dhcp server ip-pool 10 为 VLAN10分配IP地址 network 192.168.10.0 mask 255.255.255.0 gateway-list 192.168.10.1 dns-list 100.100.100.100 # dhcp server ip-pool 20 为 VLAN20分配IP地址 network 192.168.20.0 mask 255.255.255.0 gateway-list 192.168.20.1 dns-list 100.100.100.100 # dhcp server ip-pool 30 为 VLAN30分配IP地址 network 192.168.30.0 mask 255.255.255.0 gateway-list 192.168.30.1 dns-list 100.100.100.100 # dhcp server ip-pool 40 为 VLAN40分配IP地址 network 192.168.40.0 mask 255.255.255.0 gateway-list 192.168.40.1 dns-list 100.100.100.100 # interface Aux0 async mode flow # interface Ethernet1/0 ...
