微型打印机控制电路的设计摘 要： 目前，电子领域正向着数字化、信息化、微型化的方向发展。打印机作为数据输出设备之一也朝着多功能、高性能的方向发展，微型打印机是电子信息领域中一种很重要的输出设备。本设计基于TPμP-40A微型打印机，采用89S52单片机控制，利用并行接口技术，同时通过液晶显示器显示打印的数据和文字信息。可以实现打印一段固定的汉字和单个任意的数字，同时把打印的内容显示在液晶显示器上。它具有速度快、噪声低、体积小、重量轻、运行可靠、维护成本低等特点。关键词：微型打印机 单片机 液晶显示器 键盘The design of control circuit in Micro-printerAbstract ： Nowadays, electronic field is developing towards the direction of digitization 、 informatization and micromation. As one of data output equipments, the printer is also spreading out in multifunction、high-performance. And the Micro-printer is a very important output equipment in electronic information field. Based on Micro-printer——TPμP-40A, this design adopts micro-controller (89S52), makes use of parallel-interface technique and in the meantime displays printing data and word information on Liquid Crystal Display. It can print a paragraph of regular Chinese characters and single discretional number. At the same time the Liquid Crystal Display can display print content. It possesses the characteristics of high-speed、low-noise、small-volume 、lightweight、reliable running and low cost of maintenance.Keywords: Micro-printer Single Chip Computer Liquid Crystal Display Keyboard目 录1 引言………………………………………………………………………………… 12 设计要求…………………………………………………………………………… 13 系统组成…………………………………………………………………………… 14 硬件部分设计……………………………………………………………………… 24.1 打印机部分……………………………………………………………………… 24.2 单片机芯片部分………………………………………………………...
