基于PLC和变频器的电梯控制系统的设计

基于 PLC 和变频器的电梯控制系统的设计摘 要随着现代社会和城市生活进展，计算机技术、自动控制技术和电力电子技术得到了迅速的进展，电梯已经成为城市物质文明的一种标志。特别是在高层建筑中，电梯是不可或缺的垂直运输设备。传统继电器电梯控制系统，由于继电器本身的机械和电磁惯性大，大大降低了电梯系统的可靠性和安全性。为了保证电梯运行，既高效节能又安全可靠，必须改进电梯控制方式。根据顺序逻辑控制的需要进展起来的可编程控制器（PLC），它是专门为工业环境应用而设计的数字运算操作的电子装置。PLC 处理速度快，可靠性高，能够保证电梯正常、安全、可靠地运行。同时，由于电机沟通变频调速技术的进展，电梯的拖动方式己由原来直流调速逐渐过渡到了变频调速，这不仅能满足乘客的舒适感和保证平稳的精度，还可以降低能耗，节约能源，减小运行费用。本文将基于 PLC 的变频调速方法应用到电梯系统中，并对此方法进行讨论。 关键词：电梯； 可编程控制器； 变频器AbstractAlong with the development of modern economy and city life, computer technology, automatic control technology and power electronic technology rapid development, the elevator has become a symbol of urban material civilization. Especially in high-rise buildings, the elevator is an indispensable vertical transportation equipment. Traditional relay elevator control system, due to the mechanical and electromagnetic relay inertia big, greatly reduces the reliability and security of the elevator system. In order to ensure the efficiency and reliable securities, the control method of elevator must be changed. The programmable logic controller (PLC), which develops based on sequence logical control, is digital operation electronic device specialized in the industrial application environment. PLC possesses fast process speed and high reliability. Therefore, PLC can be able to ensure the elevator run normally, securely and reliably. In addition, the drive method of elevators has replaced the DC velocity modulation with ...
