摘 要20 世纪 90 年代，国际上电子和计算机技术较先进的国家，一直在积极探究新的电子电路设计方法，并在设计方法、工具等方面进行了彻底的变革，取得了巨大成功。在电子技术设计领域，可编程逻辑器件（如 CPLD、FPGA）的应用，已得到广泛的普及，这些器件为数字系统的设计带来了极大的灵活性。这一切极大地改变了传统的数字系统设计方法、设计过程和设计观念，促进了 EDA 技术的迅速进展。 本次设计在 EDA 开发平台 QUARTUSⅡ7.2 上利用 VHDL 语言设计矩阵键盘控制接口电路。要求设计一个 4×9 矩阵键盘，一共有三个模块，分别为：扫描电路模块、时钟产生模块、键盘译码电路和按键标志位产生电路。扫描模块中是为了产生扫描信号，来利用扫描信号来扫描键盘中是否有按键按下。键盘译码电路和按键标志位产生电路也是为了配合扫描模块来扫描电路中是否有按键按下，而且还要求它来产生按键标志信号，以便和外部电路握手。时钟产生电路是为了产生不同频率的信号，来驱动上面两个电路的运转。通过对课题的分析讨论，掌握了 VHDL 语言编程方法，同时也增强了个人的学习能力和动手能力。关键词： FPGA/CPLD；矩阵键盘；仿真AbstractMore countries which have advanced electronic and computer technology among the International field have been actively exploring new electronic circuit design method and design method. And they made some completely reformation in the design methods and the tools, that has achieved a huge success since the 1990s. In the Electrical Technology Design field, programmable logic device such as: CPLD, FPGA’s adhibition have been already popularized. All those devices made a great flexibility to the design of the digital system. And also changed the traditional digital system’ design methods, design procedure and the design concept immensely. And it is greatly enhanced the development of the EDA. Circuit designing that QUARTUSⅡdeveloping platform in EDA makes use of VHDL language design Matrix keyboard interface circuit on 7.2 originally time. Requirement is to design a matrix keyboard...
