大跨径变截面箱型拱式渡槽扣挂法施工技术

大跨径变截面箱型拱式渡槽扣挂法施工技术大跨径变截面箱型拱式渡槽扣挂法施工技术 摘要：箱型拱施工方法常采纳支架法、悬拼法施工。龙场渡槽是大跨度的箱型拱式渡槽，拱跨 200m，拱顶至河水位高差约 242 米，以上两种施工方法均不适用该渡槽箱型拱施工，经讨论，该渡槽主拱圈采纳缆索吊＋挂篮悬臂浇筑的扣挂法新工艺施工。本文详细阐述了扣挂系统总体构造、缆索吊机及塔机系统、塔架系统、扣锚索系统、后锚系统及挂篮系统，可为类似工程提供较好且可靠的借鉴。 关键词：渡槽；箱型拱；扣挂；塔架；扣锚索；后锚；挂篮 Abstract: the construction of the box arch may be the support method, the cantilever construction. Dragon field aqueduct is the large span box arch type aqueduct, arch span of 200 m, vault to the river a difference of about 242 meters, the above two kind of construction method is not applicable to all the aqueduct box arch construction, the research shows that the aqueduct of the main arch ring cable hoisting system + hanging basket cantilever buckle hanging method new process construction. This paper elaborated on button hang system overall structure, cable crane and installing system, tower system, buckle anchor system, after anchor system and the hanging basket system for similar projects to provide better and reliable reference. Keywords: aqueduct; Box arch; Hang buckle; Tower; Button cable; After anchor; Hanging basket 中图分类号：TU74 文献标识码：A 文章编号：2095-2104（2025） 1 工程概况 龙场渡槽是黔中水利枢纽一期工程总干渠最大跨度的箱型拱式渡槽，总长 330m，采纳单跨拱，拱跨 200m，为国内目前已知最大拱跨的钢筋混凝土渡槽。主拱为变截面悬链线箱型拱，矢高 40.35m，矢跨比 1/5，拱轴系数 m=2.24，拱箱截面高 3.5m，截面宽度从拱顶至拱脚按二次抛物线变化，拱顶截面宽 5.5m，拱脚截面宽 12.0m。主拱设置三个箱室，采纳 C45 混凝土，拱座一期采纳Ｃ 20 混凝土，二期采纳 C25 混凝土。拱上布置 13 副排架用于支承渡槽槽壳，排架间距 15.0m，采纳Ｃ 25 混凝土单排架...
