钢结构词汇参考(xsteel)-1-钢结构词汇参考(xsteel)Aactivearea有效面积ANCHOR锚ANCHORBOLT锚栓angle角钢anglebrace隅撑angleleg角钢肢anglewithequallegs等肢角钢anglewithunequallegs不等肢角钢aperture孔径archbeam拱梁areaofsection截面面积areaofstructuralsteel型钢截面面积assembly构件awning雨篷BBackplan底视图baffleplate隔板bar条钢basePL.底板backfillingplate垫板battenplate缀板battenedgrating栅格板beam次梁bearingbar横杆bearingplate支承板bend弯头(弯曲半径)bent排架bevel倾斜的,坡口bevelcut斜切BILL清单BILLOFMATERIAL材料表bracket牛腿bridging拉条(澳洲)bolt螺栓boltedsteelstructure螺栓连接钢结构building建筑built-upsteelcolumn格构式钢柱buttweld对接焊缝Ccamber拱,起拱cantileverbeam挑梁钢结构词汇参考(xsteel)-2-capPL.盖板CHUTE滑运槽circuit电路CLEANCOAL洗煤clearance净距clipangle角钢夹板COLLECTINGCONVEYOR集煤传送带column柱子columnbracing柱间支撑concrete混凝土connectionsofsteelstructure钢结构连接constantcross-sectioncolumn等截面柱continuousweld连续焊缝COUNTERWEIGHT平衡器couplingwall-beam联系梁coverplate盖板CONVEYORDESK传送台CRANE吊车cranegirder吊车梁criteria标准crossbeam井字梁custom自定义customcomponent自定义组件cyclone旋流器Ddesignationsofsteel钢材牌号detail详图,零件图,细部detailer详图员dimension尺寸(线)diaphragm横隔板doubleanglebracing双角钢支撑Eedition版本elevationview主视图embeddedparts预埋件endplate端板engineeringdrawing工程图EXPMETAL=expandedmetal金属网FF=freeze冻结fieldwelding现场焊fillerplate填板filletweld角焊缝finishfloor楼面装修层地板钢结构词汇参考(xsteel)-3-FLATTENED展平的floorboard楼面板floordepth楼板厚度floorplate楼板floortopping楼板面层flange翼缘GG=arrangedrawing布置图gablerooftruss人字形屋架gablecolumn山墙柱galvanized镀锌的grid轴线gridplane轴线平面girder主梁girth墙梁groove坡口gussetplate节点板gutter檐沟Hheadroom净高haunch腋high-strengthbolt高强度螺栓high-strengthboltedconnection高强度螺栓连接hingedconnection铰接hollowsection中空截面horizontalbracing横向水平支撑(transversebracing)horizontalstiffener横向加劲肋(transversestiffener)horizontalweld横向焊缝(transverseweld)hot-rolledsectionsteel热轧型钢HS.承压型(螺栓)hunchedbeam加腋梁II=issuev.发行inclinedsection斜截面incompletepenetration未焊透incompletelyfilledgroove未焊满intermediatestiffener中间加劲肋intermittentweld断续焊缝ITEMNO.项目编号JJackbolt定位螺栓Jagging开槽口joblocation施工现场jobshop加工车间钢结构词汇参考(xsteel)-4-jobschedule工程进度表joggledbeam拼接梁joiningbeam联系梁joiningplate连接板joist托梁jointflange接合法兰jointfree无缝的joiststeel工字钢Kkneebrace隅撑,角撑kneepipe弯管kickplate踢脚板killesse槽钢kingrod腹杆LLabelv.标注(lacev.扎带子,缚带子)lacedofbattenedcompressionmember格构式钢柱lacingandbattenelements缀材(缀件)lacingbar缀条ladder爬梯landing楼梯平台leg肢legsizeoffilletweld角焊缝焊脚尺寸LLH.=longleghorizontalangle长肢水平角钢longitudehorizontalbracing纵向水平支撑longitudinalbrace纵向拉条longitudinalweld纵向焊缝longitudinaltie纵拉杆MM=multipledrawing多构件图mainmember主构件manlockcolumn开孔柱material原料multiplespangirder多跨梁Nnon-uniformcross-sectionbeam变截面粱normalsection正截面notch槽口nut螺母Oobliquesection斜截面outlineplane主要平面钢结构词汇参考(xsteel)-5-outstandingwidthofflange翼缘板外伸宽outstandingwidthofstiffener加劲肋外伸宽度Ppaddingplate垫板part零件,部件perspectiveview透视图piecemark零件标号pipe圆管plate板plank板材portalspan门式刚架(portal入口)post立杆,小立柱PULLEYSTAND滑车架PULLEYGUARD...
