隧道监控量测施工方案......................................................................................1一、工程概况........................................................................................................1二、质量目标........................................................................................................2三、编制依据........................................................................................................2四、编制原则........................................................................................................2五、施工准备........................................................................................................35.1技术准备......................................................................................................35.2机具准备......................................................................................................35.3材料准备......................................................................................................3六、施工工艺流程图............................................................................................3七、洞口及浅埋段的监控量测（收敛及下沉）.................................................47.1监控量测的目的及意义...............................................................................47.2监控量测内容..............................................................................................47.3监控量测方法、测点布设及监测频率.......................................................5八、洞内施工时初期支护后的监控量测（收敛及下沉）................................118.1拱顶下沉....................................................................................................118.2周边收敛....................................................................................................12九、质量保证措施..............................................................................................14十、安全保证措施..............................................................................................15十一、环保措施..................................................................................................161隧道监控量测施工方案一、工程概况全标段共有5座隧道，分别是**隧道、**隧道、**隧道、**隧道、**隧道。具体情况见下表隧道情况一览表隧道名称起讫桩号围岩级别长度比例起讫桩号围岩级别长度比例**隧道ZK79+932~ZK81+674（左幅1742米）V3920.23YK79+945~YK81+707（右幅1762米）V2720.15IV8600.49IV10700.61III4900.28III4200.24**隧道ZK82+680~ZK83+280（左幅600米）V4450.74YK82+735~YK83+350.50（右幅615.50米）V370.50.60IV1550.26IV2450.40**隧道ZK84+195~ZK85+204（左幅1009米）V4840.48YK84+195~YK85+210（右幅1015米）V3850.38IV5250.52IV6300.62**隧道ZK86+447~ZK87+330（左幅891.37米）V1000.11YK86+406~YK87+305（右幅905.715米）V1240.14IV830.09IV1850.20III708.370.79III596.70.66**隧道ZK88+600~ZK89+805（左幅1205米）V1470.12YK88+575~YK89+815（右幅1240米）V1400.11IV7390.61IV6750.54III3190.26III4252二、质量目标本着“百年大计，质量第一”的指导方针。结合业主、监理等各方面要求，制定工程质量目标：1．内业资料准确、及时；2．分项工程合格率达100%，工程评分达95分以上。三、编制依据《公路工程技术标准》(JTGB001-2003)《公路工程质量检验评定标准》(JTGF80/1-2004)《公路工程施工安全技术规程》JTJ076-95《公路隧道施工技术规范》(JTJ-F60-2009)《公路工程技术标准》（JTGB01-2014）《公路施工手册—...
