75Ω 多芯微型同轴电缆系列75Ω Multi Cores Micro Coaxial Cable Series应用传送视频、音频信号，无线电接收及发射信号的传送，数字程控交换机之间的连接Applications Transmit the video and audio frequency signals, the signal of the radio apparatus when it receives or sends, and used in the connection between digital program-controlled switching equipments.型号 TypeSYV-75-2-1×8, SYV-75-2-2×8, SYV-75-3-1×8, SYV-75-3-2×8结构 Structure超五类 RJ45 模块(Enhanced category 5 RJ45 modules) 超五类 RJ45 插座模块是根据国际标准 ISO/IEC11801、TIA/EIA568 设计制造的 8 线式插座模块，性能优异，可靠性好，配合面板使用，操作使用方便。 The enhanced category 5 RJ45 socket module is 8 strings Socket Modules designed and manufactured according to international standards ISO/IEC11801、 TIA/EIA568,and it is advantageous in excellent performances and reliability, convenient to use combined with panels.技术说明 （Technical descriptions）卡接簧片整体镀镍，可接线径 0.4～0.6mm,卡接可重复次数＞200 次The seizing reed nickeled entirely. Conductor diameter: 0.4～0.6mm. Repeatable times: > 200接触电阻：正常大气压条件下 ≤2.5mΩContact resistance ：Under the regular atmospheric pressure ≤2.5mΩ绝缘电阻：正常大气压条件下 ≥1000MΩInsulation resistance： Under the regular atmospheric pressure ≥1000MΩ抗电强度：DC1000V（AC700V）1 分钟无击穿和飞弧现象Dielectric breakdown strength：No breakdowns and flashovers in 1 minute, DC 1000V (AC 700V)电话插座模块(phone socket module)电话插座模块是用于语音通信的四芯接线模块，四芯 接触针整体镀金，可接单股和多股铜导线，长期使用接触可靠The phone socket module is four-core connection module used in speech communication. The connect pins gilded entirely. Connect single or multiple copper conductors.It is reliable for long-term use.2/3 位地板插座（2/3 floor socket） 用于地面安装的插座，内含 1 位强电插座，其余...
