133 TQ-RELAYS LOW PROFILE 2 FORM C RELAY9.35426.71.0515.197+0.4–0.2+.016–.008 mm inch9.35414.5515.197+0.4–0.2+.016–.008 FEATURES •High sensitivity: 2 Form C: 140 mW power consumption (single side stable type)4 Form C: 280 mW power consumption (single side stable type) •Surge voltage withstand: 1500 V FCC Part 68•Sealed construction allows automatic washing•Self-clinching terminal also available•M.B.B. contact types available SPECIFICATIONS ContactCharacteristics Standard (B.B.M) typeM.B.B.typeArrangement2 Form C4 Form C2 Form DInitial contact resistance, max. (By voltage drop 6 V DC 1A)50 m Ω Contact materialGold-clad silverRatingNominal switching capacity (resistive load)1 A 30 V DC 0.5 A 125 V AC1 A 30 V DCMax. switching power (resistive load)30 W, 62.5 V A30 WMax. switching voltage110 V DC, 125 V AC110 V DCMax. switching current1 AMin. switching capacity f 1 10 µ A 10 mV DC Nominal operating power Single side stable 140 mW (3 to 12 V DC)200 mW (24 V DC)300 mW (48 V DC)280 mW (3 to 24 V DC) 400 mW (48 V DC) 200 mW1 coil latching 100 mW (3 to 12 V DC)150 mW (24 V DC) 200 mW—2 coil latching 200 mW (3 to 12 V DC)300 mW (24 V DC) 400 mW— Expected life (min. opera-tions) Mechanical (at 180 cpm)10 8 10 7 Electrical (at 20 cpm) (1 A 30 V DC resistive)1 A 30 V DC resistive 2 × 10 5 10 5 0.5 A 125 V AC resistive 10 5 —Standard (B.B.M) typeM.B.B.typeInitial insulation resistance* 1 Min. 1,000 M Ω (at 500 V DC)Initial breakdown voltageBetween open contacts750 Vrms for 1 min. (Detection current: 10 mA)300 Vrms for 1 min. (Detection current: 10 mA)Between contact and coil1,000 Vrms for 1 min. (Detection current: 10 mA)Between contact sets1,000 Vrms for 1 min. (Detection current: 1...
