92500DW T 轴系校中及主机安装工艺 第1 页 共 16 页 SN333-336 轴系校中及主机安装工艺 (图号:SNS-TECH-M02) 编制(Designed) 2010 年 月 日 校对(Checked) 2010 年 月 日 审核 (Verified ) 2010 年 月 日 批准 (Approved) 2010 年 月 日 山东省新船重工有限公司 92500DW T 轴系校中及主机安装工艺 第2 页 共 16 页 1 概述 overview 1.1 本系列船轴系和主机在船舶下水后,采用合理校中法进行安装。 After launching the ship, install the shafting and main engine with proper alignment. 1.2 主机底座采用环氧树脂垫片,中间轴承采用钢质垫片。 The main engine base adopts epoxy resin gasket, and the intermediate bearing adopts steel gasket. 2 图纸和技术文件 Drawing and Technical Documents 轴系布置图 shafting arrangement drawing 主机安装图 the drawing of main engine installation 主机顶撑布置图 arrangement of the main engine top-up 轴系校中计算书 calculation of shaft alignment 检验项目表 inspection item list MAN B&W 主机安装工艺文件 MAN B&W main engine installation document 3 工艺流程 Technological process 主机轴系校中包括三个阶段,其主要工作如下: Alignment of Shafting and Installation of the Main Engine include three steps. Main works as follows: 3.1 连接轴系螺栓前 Before connecting the shafting bolt a 主机输出端法兰和中间轴法兰螺栓孔铰孔 Reaming for the flange of the main engine output end and flange bolt hole of the intermediate shaft b 轴系校中,调整法兰的偏移(SAG)和曲折(GAP) Align the shafting and adjust the SAG and GAP of flanges c 检查主机机座水平挠度 Check the horizontal deflection of the main engine base. d 检查曲轴甩档 Check the crank shaft deflection e 冷冻法安装轴系铰制螺栓 Install shafting reamer bolt with freezing method 92500DW T 轴系校中及主机安装工艺 第3 页 共 16 页 3.2 连接轴系螺栓后,浇注环氧前(主机定位) After connecting the shafting bolt and before pourin...
