Philips Semicondu ctorsProdu ct specification TriacsBT134 series GENERAL DESCRIPTIONQUICK REFERENCE DATAGlass passivated triacs in a plasticSYMBOLPARAMETERMAX.MAX.MAX. UNITenvelope,intendedforuseinapplicationsrequiringhighBT134-500600800bidirectional transient and blockingBT134-500F600F800Fvoltage capability and high thermalBT134-500G600G800Gcyclingperformance.TypicalVDRMRepetitive peak off-state500600800Vapplications include motor control,voltagesindustrialanddomesticlighting,IT(RMS)RMS on-state current444Aheating and static switching.ITSMNon-repetitive peak on-state252525AcurrentPINNING - SOT82PIN CONFIGURATIONSYMBOLPINDESCRIPTION1main terminal 12main terminal 23gatetabmain terminal 2LIMITING VALUESLimiting values in accordance with the Absolute Maximum System (IEC 134).SYMBOLPARAMETERCONDITIONSMIN.MAX.UNIT-500-600-800VDRMRepetitive peak off-state-50016001800VvoltagesIT(RMS)RMS on-state currentfull sine wave; Tmb ≤ 107 ˚C-4AITSMNon-repetitive peakfull sine wave; Tj = 25 ˚C prior toon-state currentsurget = 20 ms-25At = 16.7 ms-27AI2tI2t for fusingt = 10 ms-3.1A2sdIT/dtRepetitive rate of rise ofITM = 6 A; IG = 0.2 A;on-state current afterdIG/dt = 0.2 A/µstriggeringT2+ G+-50A/µsT2+ G--50A/µsT2- G--50A/µsT2- G+-10A/µsIGMPeak gate current-2AVGMPeak gate voltage-5VPGMPeak gate power-5WPG(AV)Average gate powerover any 20 ms period-0.5WTstgStorage temperature-40150˚CTjOperating junction-125˚CtemperatureT1T2G1231 Although not recommended, off-state voltages up to 800V may be applied without damage, but the triac mayswitch to the on-state. The rate of rise of current should not exceed 3 A/µs.August 19971Rev 1.200Philips SemiconductorsProduct specification TriacsBT134 series THERMAL RESISTANCESSYMBOLPARAMETERCONDITIONSMIN.TYP.MAX.UNITRth j-mbThermal resistancefull cycle--3.0K/Wjunction to mounting b...
