Shenzhen Outest Technology Co., LTD Rev. A Report No.: OTE1006001136 Page 1 / 19 EMC TEST REPORT Product Description : Mobile Battery Model No. : BL-4B Report No. : OTE1006001136 Test Date : Jun. 18 to 25, 2010 Regulations : See below Standards Resu lts (Pass/Fail) EN 61000-6-3: 2007 EN 61000-6-1: 2007 - IEC 61000-4-2: 2001 - IEC 61000-4-3: 2006 PASS PASS PASS PASS Prepared For Shenzhen Waystrengthen Electronics Technology Co.,Ltd. Bldg 3, Hongye Industrial Park, Lezhujiao, Jiuwei, Xixiang Town, Bao'an District, Shenzhen, Guangdong, China. Prepared By Shenzhen Outest Technology Co., LTD 17th Floor, Tianyuan Building, Bao’an 31 District, Shenzhen, Guangdong, China (518101) TEL: 86-755-26415344 FAX: 86-755-27841136 Shenzhen Outest Technology Co., LTD Rev. A Report No.: OTE1006001136 Page 2 / 19 TABLE OF CONTENTS DESCRIPTION PAGEREPORT DECLARATION 3 SUMMARY OF TEST RESULTS 4 1. GENERAL INFORMATION 5 1.1 SYSTEM DESCRIPTION 5 1.2 SUPPORT EQUIPMENT 5 1.3 TEST FACILITY 5 1.4 TEST EQUIPMENT LIST 6 2. EN 61000-6-3 RADIO DISTURBANCE CHARACTERISTICS 7 2.1 MEASUREMENT PROCEDURE & LIMIT (RADIATION EMISSION TEST) 7 2.2 BLOCK DIAGRAM OF TEST SETUP 8 2.3 SUMMARY DATA 9 3. EN 61000-6-1 IMMUNITY CHARACTERISTICS - IEC 61000-4-2 (ELECTROSTATIC DISCHARGE) 12 3.1 BLOCK DIAGRAM OF TEST SETUP 12 3.2 TEST PROCEDURE 13 3.3 PERFORMANCE & RESULT 13 4. EN 61000-6-1 IMMUNITY CHARACTERISTICS - IEC 61000-4-3 (RADIATED ELECTROMAGNETIC FIELD)15 4.1 BLOCK DIAGRAM OF TEST SETUP 15 4.2 TEST PROCEDURE 16 4.3 PERFORMANCE & RESULT 16 5. PRODUCT LABELING 17 5.1 PROPOSE CE LABEL FORMAT 17 5.2 PROPOSED LABEL LOCATION ON EUT 17 APPENDIX I PHOTOGRAPHS OF EUT 18 Shenzhen Outest Technology Co., LTD Rev. A Report No.: OTE1006001136 Page 3 / 19...
