LabVIEWCLAD认证模拟题详解NEW

LabVIEWCLAD认证模拟题详解NEW_第1页
1/18
LabVIEWCLAD认证模拟题详解NEW_第2页
2/18
LabVIEWCLAD认证模拟题详解NEW_第3页
3/18
LabVIEW CLAD 认证模拟题详细解答 关于CLAD认证考试 CLAD ( Certified LabVIEW Associate Developer ) 即 LabVIEW 助理开发工程师认证,是NI LabVIEW 专业认证的第一步,获得CLAD 认证证明您在LabVIEW 环境下的专长,能基本熟练地在测试和测量应用中运用虚拟仪器技术和产品 。 如您获得了 CLAD 认证,可在您简历中使用LabVIEW助理开发工程师标志,为就业与事业发展增加机会。 CLAD认证模拟题详细解答 1. Where can a VI be documented so that the description appears in the Show Context Help popup window? a. In the VI Properties Documentation window b. Typing in the Show Context Help window c. Creating a free label on the front panel d. Editing the LabVIEW help files 正确答案: A 分析:在VI Properties中的Documentation可以输入对此 VI的说明与描述,保存后,在查看此 VI时会在Context Help窗口中显示此条描述。 2. Can a wire be used to pass data between loops that are intended to run in parallel? a. Yes b. No 正确答案: B 分析:一般使用Local Variable或者Queue等方式实现并行循环间的数据传输,单纯的连线是无法做到的。 3. Which of the following describe a Tab Control ? a. A control that outputs ASCII values equal to the selected tab label b. A type of enumerated control c. A control that outputs a cluster of the controls / indicators on the tabs d. A control that outputs the tab order of the controls on the front panel 正确答案: B 分析:Tab Control即是选项卡控件,虽然在控件中的每一个 Tab中都能放很多显示控件,但是其实质是一个枚举类型(enumerated)。 4. Which server must be started before running DataSocket Vis a. HTTP server b. Data Socket server c. FTP server d. OPC server 正确答案: B 分析:使用DataSocket VI进行数据传输时,需要首先将 DataSocket服务器打开。 5. A coercion dot indicates that: a. The data types are consistent b. A polymorphic operation will be performed on the data c. A data buff...
