变形体接触问题实例.txt31岩石下的小草教我们坚强,峭壁上的野百合教我们执著,山顶上的松树教我们拼搏风雨,严寒中的腊梅教我们笑迎冰雪。| Version : Mentat 3.3 *alias action *procedure_pause 0 |*exec_p gen_image.proc @top() *action | figure 7.0 - dummy *action | figure 7.1 - dummy *action | figure 7.2 - dummy | | step 1 | @push(meshgen) @push(coord_system) *grid_u_domain 0 8 *grid_u_spacing 1 *grid_v_domain 0 5 *grid_v_spacing 0.5 *set_grid on *fill_view @pop(1) @push(plot_screen) *set_point_labels on @pop(1) | | create a surface corresponding to the tube | length=8.0, inner diam=4.0, outer diam=4.3 | *add_surfaces point( 0.000000000000e+00, 4.000000000000e+00, 0.000000000000e+00) point( 8.000000000000e+00, 4.000000000000e+00, 0.000000000000e+00) point( 8.000000000000e+00, 4.500000000000e+00, 0.000000000000e+00) point( 0.000000000000e+00, 4.500000000000e+00, 0.000000000000e+00) @push(move) *set_move_translations 0 -0.2 0 *move_points 3 4 # | End of List *action | figure 7.3 @pop(1) @push(coord_system) *system_cylindrical @pop(1) *add_points 5 15 0 16 15 0 *set_grid off *fill_view @push(coord_system) *system_rectangular @pop(1) @push(duplicate) *set_duplicate_translations 0 .6 0 *duplicate_points 5 6 # | End of List @pop(1) *add_surfaces 5 6 8 7 *action | figure 7.4 @push(move) *set_move_translations 0 1.25 0 *move_surfaces 2 # | End of List *action | figure 7.5 @pop(1) | | mesh the tube 8x3 elements | mesh the tool 14x6 elements | @push(convert) *set_convert_divisions 8 3 *convert_surfaces 1 # | End of List *set_convert_divisions 14 6 *convert_surfaces 2 # | End of List @push(plot_screen) *set_points off *set_point_labels off *set_surfaces off *regenerate *action | figure 7.6 | | select the marc element type | @pop(1) @pop(1) @pop(1) @push(jobs) @push(e...
