比亚迪GGR轿车门系统结构图册

精品文档---下载后可任意编辑CAR BODY DOOR图 5-2-1图 5-2-1 前舱附件图 5-2-2 前门总成图 5-2-1序号No.零件编号Part No.名称Description数量Qty备注Rem中 文Chinese英 文English1G3-8402180前舱盖锁体总成LOCK DEVICE ASSY,ENGINE HOOD12Q1800612T1F3六角法兰面承面带齿螺栓HEX-BOLT FLANGE3镀 彩锌3G3-8402117发动机罩锁环LOCK WREATH ENGINE HOOD14G3-8402121发动机罩撑杆STAY ROD ASSY ENGINE HOOD15G3-8402123-C1前舱盖撑杆卡座 SEAT, STAY ROD ASSY,ENGINE HOOD16BYDF3-8402122发动机罩撑杆固定孔护套JIACKET, STAY ROD ASSY,ENGINE HOOD17BYDF3-8402160前舱盖右铰链总成HINGE ASSY, ENGINE HOOD,R18BYDF3-8402150前舱盖左铰链总成HINGE ASSY, ENGINE HOOD,L.19Q1840816T1F3六角法兰面螺栓HEX-BOLT FLANGE4图 5-2-1 前舱附件序号No.零件编号Part No.名称Description数量Qty备注Rem中 文Chinese英 文English10Q1860820TF3六角法兰面螺栓-加大系列HEX-BOLT FLANGE,LARGED411BYDF3-8402170发动机机罩内控扣手及拉索总成INNER HANDLE & CABLE ASSY, ENGINE HOOD112BYDF3-8402211前舱盖侧缓冲块BUFFER CUSHION,ENGINE HOOD213BYDF3-5302133前舱前缓冲块BUFFER CUSHION, UPPER MEMBER, RADIATOR2精品文档---下载后可任意编辑图 5-2-2 前门总成图 5-2-2 前门总成图 5-2-2 前门总成序号No.零件编号Part No.名称Description数量Qty备注Rem中 文Chinese英 文English1BYDF3-6106130左前侧门下铰链总成LOWER HINGE ASSY,FRONT DOOR, L12BYDF3-6106140右前侧门下铰链总成LOWER HINGE ASSY,FRONT DOOR, R13Q1460825T1F3六角头螺栓、弹簧垫圈和平垫圈组合件HEX-BOLT，SPRING WASHER AND FLAT WASHER COMP84BYDF3-6106139侧门铰链承面带齿凸台螺栓HEX-BOLT FLANGE85BYDF3-6106110左前侧门上铰链总成UPPER HINGE ASSY, FRONT DOOR, L17BYDF3-6109110B左前侧门限位器总成LIMITER ASSY, FRONT DOOR, L1售后用BYDF3-6109110左前侧门限位器总成LIMITER ASSY, FRONT DOOR, L18BYDF3-6109120B右前侧门限位器总成LIMITER ASSY, FRONT DOOR, R1售后用BYDF3-6109120右前侧门限位器总成LIMITER ASSY, FRONT DOOR, R19Q1840816T1F3六角法兰面螺栓（镀黑锌）HEX-BOLT FLANGE2图 5-2-2 前门总成序号No.零件编号Part No.名称Description数量Qty备注Rem中 文Chin...
