排阻封装尺寸

YAGEO CORPORATION SMD RESISTORSSCHEMATICSThick FilmChip Resistors Netw orkYC Series[ For 8Pin/4R ]APPLICATIONSTelecommunication Equipment Lap-Top and Note-Book ComputerR1=R2=R3=R40.6 ±0.10.3±0.1512348765R1R2R3R4YC12YC16YC32DIMENSIONSYC12YC160.65 ±0.050.3±0.152.0 ±0.20.45 ±0.10.5 ±0.050.45 ±0.050.2±0.151.0±0.150.3±0.150.3 ±0.05YC320.9 ±0.153.2 ±0.21.1 ±0.151.27 ±0.050.5±0.20.5±0.153.2±0.20.6 ±0.10.8 ±0.050.5 ±0.153.2 ±0.25.08 ±0.2Unit : mmYC12YC16YC321.6±0.1521Note :ELECTRICAL CHARACTERISTICSSTYLEYC12YC16YC32Power Rating at 70°C1/16W1/8WOperating Temp. Range-55ºC to +125ºCMaximum Working Voltage50V200VMaximum Overload Voltage100V400VDielectric Withstand Voltage100V500VNumber of Resistors4Resistance Range10Ω ~ 1MΩTemperature Coefficient±200ppm/ºCResistance Tolerance±5%ENVIRONMENTAL CHARACTERISTICSPERFORMANCE TESTTEST METHODAPPRAISETemperature CoefficientMIL-STD-202F, Method 304-55°C to +125°Cby TypeThermal ShockMIL-STD-202F, Method 1075 Cycles, -55°C to +125°C (Step by Step 2min.)±(1%+0.05Ω)Low Temperature OperationMIL-R-55342D, Para.4.7.4One Hour at -65°C Followed by 45 Minutes RCWV±(1%+0.05Ω)Short Time OverloadMIL-R-55342D, Para.4.7.52.5 Times RCWV for 5 Seconds±(2%+0.05Ω)Insulation ResistanceMIL-STD-202F, Method 302RCOV for 1 Minute>10GΩDielectric Withstand VoltageMIL-STD-202F, Method 301R.M.S. for 1 Minuteby TypeResistance to Soldering HeatMIL-STD-202F, Method 210CSoldered to Test Board at 260ºC for 10 Seconds±(1%+0.05Ω)Moisture ResistanceMIL-STD-202F, Method 106F42Cycles.Total 1000 Hours±(2%+0.05Ω)LifeMIL-STD-202F, Method 108A1000 Hours at 70°C RCWV Intermittent±(3%+0.10Ω)SolderabilityMIL-STD-202F, Method 208G230°C for 5 Seconds>95% CoverageBending StrengthJIS-C-5202, Para.6.1.4 Unit Mounted in Center of 90mm Board Length,±(1%+0.05Ω)Deflected 1mm in Eithe...
