机械及模具英文翻译

NOTES:12345678910111213141516171819NOTES:1CoverFunctionPart23456789101112NOTES:12345LensPart678910111213CRITICAL TO FIT OR FUNCTION (5X). 关键装配尺寸或者功能尺寸的个数为5。MATERIAL TO BE PC+ABS FR40 (GE CYCOLOY C6600) OR (DOW CELEX 5200HF).CYCOLOY IS A REGISTEREDTRADEMARK OF GE. CELEX IS A REGISTERED TRADEMARK OF DOW.COLOR TO BE LIMESTONE WHITE.MATERIAL MUST MEET THE COLOR MATCHREQUIREMENTS OF LEXMARKENG. SPEC. 1041532 SECTION 5.2.4. COLOR MATCH "C".材料为PC+ABS,牌号是GE CYCOLOY C660 或者DOW CELEX 5200HF。CYCOLOY 是GE的一个注册商标，CELEX是DOW的一个注册商标。颜色是LIMESTONE WHITE。材料必须满足Lex mark规格1041532选项5.2.4的颜色匹配要求。颜色匹配等级为“C”。 NO PBB'S, PBBE'S, PBD'S, OR PBDE'S, BROMINATED DIOXINS,BROMINATED FURANS, PVC, CHLORINATED PARAFFINS, MATERIALS THAT CAN FORM THESE COMPOUNDS,OR SUSPECTED CARCINOGENS, INCLUDING ANTIMONY COMPOUNDS, METALS ORCOMPOUNDS OF CADMIUM, HEXAVALENT CHROMIUM, LEAD OR MERCURY ARE PERMITTEDUNLESS OTHERWISE NOTED IN THE ROHS/WEEE DIRECTIVE OR SPECIFIED ON THE PRINT.禁止使用多溴联苯，多溴联苯化合物，多溴聯苯醚，多溴聯苯醚化合物，溴化二氧芑，溴化呋喃，聚氯乙烯，氯化石蠟,含有这些化合物或者可疑的致癌物质，包括锑化物，金属或者镉，六价铬，铅或者汞，除非在RoHS/WEEE中有另外的指明，或者在图面上有特别说明。NOMINAL GEOMETRY IS ESTABLISHED BY THE WIRE FRAME DATA. THE FOLLOWINGTOLERANCES WITH RESPECT TO ESTABLISHED DATUMS APPLY UNLESS OTHERWISE SPECIFIED: 0 TO 6 MM: +/-0.1> 6 TO 16 MM: +/-0.15> 16 TO 30 MM: +/-0.2> 30 TO 120 MM: +/-0.3> 120 TO 315 MM: +/-0.5> 315 MM: +/-0.8实际的几何体是通过线框创建的，除非特别说明，一般公差如下所示：MATERIAL TO BE UL RECOGNIZED PLASTIC RATED UL FLAME CLASS94 V1 CLASS MINIMUM. THICKNESS OF PRIMARY WALL IS 2.5 MM.在基本肉厚为2.5mm时，材料防火等级最小为UL 94 V1。MAXIMUM OF 25% FIRST GENERATION ONLY REGRIND ALLOWED. USE ONLYREGRIN...
