四川理工学院毕业设计 基于单片机的数据采集与传输系统设计学 生：马良尧学 号：09021020255专 业：电子信息工程班 级：2025.2指导老师：陶思言 李庆隆 四川理工学院自动化与电子信息学院二 O 一三年六月基于单片机的数据采集与传输系统设计摘要：本文介绍了基于单片机的数据采集与传输系统的硬件设计和软件设计，数据采集系统是模拟域与数字域之间必不可少的纽带，它的存在具有着非常重要的作用。本系统应用 ADC0809 作为高速数据转换电路使其能够进行 8 路数据实时采集，实现对采集到的数据进行模拟量到数字量的转换，并将采集到的实时数据通过 RS232 传输到上位 PC 机上。本系统将比较热门的 A/D 转换技术和单片机技术有效的结合，实现了高速的通信和数据交换。系统能够对多个点进行同时监控，且能够与微机进行通信，可以方便的实现人机对话。软件部分应用 VC++编写控制软件，对数据采集系统、模数转换系统、数据显示、数据通信等程序进行了设计。关键词：数据采集；数据传输；ADC0809；RS232；单片机Design of Data Acquisition and Transmission System Based on Single Chip MicrocomputerMA Liangyao(Sichuan University of Science and Engineering, Zigong, China, 643000)Abstract: This article describes the hardware design and software design of the data on which based on signal-chip microcomputer. The data acquisition system is the link between the digital domain and analog domain. It has an very important function. The system applies ADC0809 as a high speed data conversion circuit to 8 road data real-time acquisition, implementation of the collected data to convert the analog quantity to digital quantity, and the transmission of real-time data were collected through RS232 to the upper PC. This system will be popular in the A/D conversion technology and single-chip microcomputer technology effectively combined, realize the high-speed communication and data exchange. System can carry on the monitoring at the same time, to the multiple points and able to communicate with computer, ...
