CAD图纸中的英语

CAD 图纸中的英语(50 页)Good is good, but better carries it.精益求精，善益求善。引用 图纸中的英语 ALL WELDS CONTINUOUS UNLESS OTHERWISE STATED. 未注焊缝均为连续焊ALL WELDS 3mm FILLET UNLESS OTHERWISE STATED 未注焊角高3mm.ALL UNSPECIFIED RADI - R3 未注圆角 R3REMOVE ALL BURRS AND SHARP EDGES 棱角倒钝CHANNEL 槽钢RSA 708 角钢 70X70X8M30X1.5 pitch M30X1.5 的锥螺纹Tackweld 点焊OD 1/4" outside dimension 1/4"的缩写 外径直 1/4"75 CRS 尺寸为 75 材质为冷轧钢板410 OPENING REF 410 开口参考尺寸40 REF 尺寸为 40,参考值2.5" BSP 2.5” 圆锥管螺纹2.5" BSPT HEXAGON 2.5” 六角圆锥管螺纹(即对丝)30x2.5 FLAT BAR 30X2.5 扁钢TYP 2 POSNS 2 处11 TOTAL COILS APROX.9 WORKING COILS APROX.RIGHT HAND WOUND ONLY,END COILS SQUARE TO TOUCH.总圈数约 11 圈；工作圈数约 9 圈；右旋；弹簧的端部磨平以便于接触.(此为弹簧技术说明)FEMALE: 内扣(母扣)MALE: 外扣(公扣)偏心轴 eccentric shaft 销轴 PIN开口销 COTTER PIN螺杆 screw紧定螺钉 SET SCREW圆螺母 ROUND NUT内六角螺钉 SOCKET HEAD CAP SCREW六角紧定螺钉 HEX HD SETSCREW 六角螺栓 HEX HD BOLT 挡圈 closing ring 弹性挡圈 circlip 轴承隔套 distance sleeve of axletree轴承 axletree深沟球轴承 DEEP GROOVE BALL BEARING 无扣长 non-buckle longth 弹簧 SPRING 吊环螺钉 LIFTING EYE BOLT 开槽盘头螺钉 SLOTTED PAN HEAD SCREW 圆锥滚子轴承 TAPERED ROLLER BEARING 推力球轴承 THRUST BALL BEARING平键 FLAT KEY 弹簧垫圈 SINGLE COIL SPRING WASHER 平垫圈 FLAT WASHER 螺母 FULL NYLOCK NUT 圆螺母 ROUND NUT缩写 全称 翻译ACCESS Accessory 附件ADJ Adjustable, Adjust 调整ADPT Adapter 使适应ADV Advance 提前AL Aluminum 铝ALLOW Allowance 允许ALT Alternate 改变ALY Alloy 合金AMT Amout 数量ANL Anneal 锻炼ANSL Amer Natl Stds Institute APPROX Approximate 大约ASME Amer Society of Mech Engrs ASSEM Assemble 装配ASSY Assembly 装配AUTH Authorized 授权的AUTO Automatic 自动的AUX Auxiliary 辅助的AVG Average...
