Date:Sep.07,2011Version:2.04.01Page:2/18TABLEOFCONTENTS目錄00.SpecificationRevisionRecord[規格變更記錄].………………………………………0300.DimensionDrawing[尺寸圖].………………………………………………….………0401.Circumscription[範圍].………………………………………………………………….0502.Features[特性].……………………………………………………………………………..0503.GeneralSpecification[規格總則].………………………………………………………...0504.EnvironmentalCharacteristics[環境特性].…………………………………………….0505.OpticalCharacteristics[光學特性].………………………………………………………0606.ElectricalCharacteristics[電子特性].……………………………………………………0607.Durability[耐久性].………………………………………………………………….………0608.MechanicalCharacteristics[機械特性].………………………………………………...0709.Reliability[信賴性].………………………………………………………………………….0810.Linearity[線性].………………………………………………….…………………………..0911.AppearanceInspection[外觀檢查].………………………………………………………1012.AttentionforMountingCondition[裝機注意事項].……………………………..……….1113.Caution[注意事項].…………………………………………………………………………...12/1314.Warranty[保固].…………………………………………………………………………….14/1515.Appendices[附註].…………………………………………………………………………15-AppendixⅠ[附註一]：DesignGuide[設計指南]……………………….………16/17-AppendixⅡ[附註一]：AppearanceSpecification[外觀檢查規格]…………...…18Date:Sep.07,2011Version:2.04.01Page:3/18SPECIFICATIONREVISIONRECORD規格變更記錄Customer[客戶名稱]：Date[發行日期]：Sep.07,2011CustomerNO.[客戶編號]：Model[型式]：T150S-XDN042G-3S02R0-059PNNO.[項次]Version.[版本]Date[變更發行日期]SummaryofChanges[變更內容摘要]Page[變更頁碼]Date:Sep.07,2011Version:2.04.01Page:5/1801.Circumscription[範圍]ThespecificationisforProjectedCapacitiveTouchPanelmodules.[此規格適用於投射電容式觸控屏幕]02.Features[特性]Item[項目]Specifications[規格](1)Type[型式]ProjectiveCapacitive[投射電容式](2)InputMode[操作模式]Finger[手觸](3)Connector[連接方式]FPC03.GeneralSpecification[規格總則]Item[項目]Specifications[規格](1)FrameSize[外框尺寸]346.00±0.30X270.00±0.30mm(2)ViewArea[可視區]305.00±0.20X229.00±0.20mm(3)Active/PrecisionArea[動作區]306.20±0.20X230.20±0.20mm(4)TotalThickness[總厚度]2.45±0.30mm(5)TailLength[出線長度]59.00±3.00mm(6)I/OChannel[出線pin腳數]X=40pin/Y=33pin04.EnvironmentalCharacteristics[環境特性]Item[項目]Specifications[規格]Temperature[溫度]Humidity[濕度](NonCondensing)[不可結露](1)Operation[操作]-20°C~+70°C20%RH~85%RH(2)Storage[儲存]-40°C~+80°C10%RH~90%RHNote:Testingenvironmentisundernormalatmospherepressure.[註:於正常的1大氣壓下]※Whentheambienttemperatureisabove65°C,thehumidityisallowedtobebelow50%RH.[65°C以上高溫環境時，濕度允許在50%RH以下]Date:Sep.07,2011Version:2.04.01Page:6/1805OpticalCharacteristics[光學特性]Item[項目]Specifications[規格](1)Transparency[透光度]90%±3%(2)Haze[霧化度]<2%※measuredbyBYK-Gardner06ElectricalCharacteristics[電子特性]Item[項目]Specifications[規格](1)Response[作動時間]AccordingtoIntegrationtimeofcontroller(2)Insulation[絕緣阻抗]≧100MΩ/25V(DC)(3)Linearity[線性]X≦1.0%,Y≦1.0%(SeeFigure10-1)07Durability[耐久性]Item[項目]Specification[規格](1)KnockTest[觸擊測...
