模具英语专业术语模具的分类:冲压模(五金模):stampingdie分离模:cuttingdie成形模:formingdie塑胶模:plasticsmold注射模:injectionmold压缩模:compressionmold铸塑模:transfermold吹塑模:blowmold吸塑模:suckmold铸造模:castingdie砂型铸造:sandcasting压铸模:diecasting锻造模:forgingdie塑胶模具术语一、入水：gate进入位(入水点)：gatelocation水口形式：gatetype大水口(侧浇口):edgegate潜水口:sub-gate薄膜式水口:filmgate牛角式潜水口:bananagate扇形水口:fangate环形水口:ringgate二次水口:细水口：pin-pointgate水口大小：gatesize转水口：switchingrunner/gate唧嘴口径：spruediameter直接水口:directgate二、流道:runner热流道：hotrunner,hotmanifold热嘴冷流道:hotsprue/coldrunner唧嘴直流:directspruegate圆形(整圆/半圆)流道：round(full/half)runner矩形流道:rectanglerunner梯形流道:trapezoidrunnerU形流道:Ushaperunner流道电脑分析(模流分析)：moldflowanalysis流道平衡:runnerbalance热嘴：hotsprue/tip热流道板：hotmanifold发热管：cartridgeheater探针:thermocouples插头：connectorplug插座：connectorsocket密封/封料：seal三、运水：waterline喉塞：lineplug喉管：tube塑胶管：plastictube快速接头：jiffyquickconnectorplug/socket四、模具零件：moldcomponents三板模(细水口模)：3-platemold二板模(大水口模)：2-platemold热流道模具:hot-runner/manifoldmold叠层模:stackedmold边钉/导边：leaderpin/guidepin边司/导套：guidepin/guidebushing直导套：shoulderguidebushing有托导套：straightguidebushing中托司：ejectorguidebush中托边：ejectorguidepin回针:returnpin面板:topclampplateA板:Aplate推板：stripperplateB板:Bplate托板：supportplate方铁:spacerblock加高方铁:higherspacerblock顶针固定板：ejectorretainnerplate顶针板：ejectorplate底板:bottomclampplate螺丝：screw杯头螺丝:socketcupheadscrew平头螺丝:socketflatheadscrew机米螺丝:外六角头螺丝:bolt栓打螺丝(等高螺丝)：S.H.S.B管钉：dowelpin开模槽：plybarsocket内模管位(模仁互锁)：core/cavityinter-lock顶针：ejectorpin司筒：ejectorsleeve司筒针：sleeveejectorpin缩呵：movablecore,returncore,corepuller扣机（尼龙拉勾）：nylonlatchlock斜顶：lifter模胚（架）：moldbase上内模：cavityinsert下内模：coreinsert行位（滑块）：slide行位扣:镶件：insert压座/斜鸡：wedge耐磨板/油板：wearplate压条：gib撑头:supportpillar唧嘴：spruebushing挡板：stopplate定位圈(法兰)：locatingring锁扣(模锁)：latch扣鸡：partinglockset推杆：pushbar顶板：eracuretun活动臂：leverarm分流锥：spuresperader水口司:bush垃圾钉：stoppin隔片：buffle弹弓柱：springrod弹弓:diespring型腔(前模仁):cavity型芯(后模仁):core镶针：insertpin销子(销钉)：dowelpin波子弹弓：ballcatch喉塞(堵头):pipeplug锁模块：lockplate斜顶杆：angleejectorrod斜顶针：anglefrompin尼龙拉勾：partinglocks活动臂：leverarm复位键、提前回杆：earlyreturnbar气阀：valves斜导边(斜导柱)：anglepin油缸:hydrauliccylinder液压马达:hydraulicmotor齿轮:gear轴承:bear术语：terms承压平面平衡：partingsurfacesupportbalance分模面排气：partinglineventing回针碰料位：returnpinandcavityinterference模总高超出啤机规格：moldbaseshuthight顶针碰运水：waterlineinterfereswithejectorpin料位出上/下模：partfromcavity(core)side模胚原身出料位：cavitydirectcutonA-plate,coredirectcutonB-plate.不准用镶件：Donotuse(core/cavity)insert用铍铜做镶件：useberylliumcopperinsert初步模图设计：preliminarymolddesign正式模图设计：finalmolddesign反呵：reversecore弹弓压缩量：springcompressedlength稳定性好：goodstability,stable强度不够：insufficientrigidity均匀冷却：evencooling扣模(粘模)：sticking顶白:stressmark热膨胀：theroexpansion缩水:shrinkage物料表:BOM原料:rawmate...
