GSM 家电控制系统的设计(梁伟源)摘 要GSM 网络技术的远程设备监控系统中，数据的可靠传输是一个关键问题。设计了利用 GSM 网络进行远程数据传输的技术方案，给出了硬件结构和软件组成。数据由以AT89S52 单片机为核心的数据采集终端采集，通过向 GSM 模块发送ＡＴ指令完成数据信息的传输。通过软硬件设计和调试实验，数据传输可靠，运行状态稳定，可应用于数量多、覆盖面广的设备远程实时监控系统中，具有广阔的应用前景。 GSM 模块，配合AT89S52 单片机，还有继电器，那么就可以用手机法短信来控制家用电器，比如，日光灯，电视，空调等。热释电人体红外感应器，GSM 模块，以及 AT89S52 单片机，可以实现，当有小偷闯入家里，可以通过 GSM 模块发短信或打电话通知我们。关键词：GSM 模块；AT89S52；单片机；人体红外感应器；DS18B20；字符液晶 1602；红外接收头 1838The Design of GSM Appliance Control System AbstractRemote device monitoring system of the GSM network technology ， the reliable transmission of data is a key issue. Use the GSM network for remote data transmission， given the hardware and software components. The data collected by the microcontroller AT89S52 as the core data collection terminals， to complete the transmission of data to send AT commands to the GSM module. Hardware and software design and debugging experiments ， the data transmission is reliable， stable running state， can be applied to a number， cover a wide range of equipment ， remote real-time monitoring system has broad application prospects. GSM module with AT89S52 microcontroller， as well as relay， then you can use the phone method SMS to control household appliances such as fluorescent lights ， TV ， air-conditioning. Infrared sensor ， GSM module ， and the microcontroller AT89S52 can be achieved， when thieves broke into the home， you can send text messages through GSM module or by telephone to inform us. Keywords: GSM module; AT89S52 is; microc...
