25MW 凝汽式汽轮机组热力设计学生姓名： 学号：学 院：专 业：指导老师：2024 年 6 月陈淑婧1227024207中 北 大 学 （ 朔 州 校区）热能与动力工程张志香精品文档---下载后可任意编辑30MW 凝汽式汽轮机组热力设计摘 要本课题针对 30MW 凝汽式汽轮机组进行热力设计，在额定功率下确定汽轮机型式及参数，使其运行时具有较高的经济性，并考虑汽轮机的结构、系统、布置等方面的因素，以达到“节能降耗，保护环境”的目的。本文首先对汽轮机进行了选型，对汽轮机总进汽量进行了计算、通流部分的选型、压力级比焓降分配及级数的确定、汽轮机级的热力计算、漏气量的计算与整机校核等。根据通流部分选型，确定排汽口数与末级叶片、配汽方式和调节级的选型，并进行各级比焓降分配与级数的确定；对各级进行热力计算，求出各级通流部分的几何尺寸，相对内效率，实际热力过程曲线。根据热力计算结果，修正各回热抽汽点压力达到符合实际热力过程曲线的要求，并修正回热系统的热力平衡计算，分析并确定汽轮机热力设计的基本参数。关键词：汽轮机，凝汽式，热力系统，热力计算Thermodynamic design of 30MW condensing steam turbineAbstract This topic for 30MW steam turbine unit for thermal design, seek appropriate turbine at rated power, to make it run with higher economic and to considered to steam turbine structure, system and arrangement and parts. So it can achieve "energy saving, environmental protection" purpose.Determination of machine, firstly, the steam turbine for the selection of the turbine total inlet were calculated through flow part of the selection pressure enthalpy drop distribution and series, steam turbine thermodynamic calculation, the leakage amount of calculation and check. According to the through flow part of selection to determine the exhaust port number and the last stage blades of steam distribution mode and regulation level selection, and for different levels of specific enthalpy drop distribution and the series of levels with a thermodynamic calculation for at all levels through ...
