传感器毕业设计

精品文档---下载后可任意编辑摘要与关键词 II引言 21 工作原理 21.1 汽车车速传感器的工作原理 21.2 车速传感器 21.2.1 霍尔式车速传感器 21.2.2 磁电式车速传感器 31.2.3 加速度传感器 41.3 控制装置的工作原理 41.3.1 ABS 控制原理 41.3.2 ECU 控制原理 52 车辆限速装置的设计 52.1 控制装置系统的设计 52.2 数据采集系统的设计 62.3 系统总体设计 63 车辆限速装置的性能测试 83.1 性能指标 83.2 测试方法与结果 83.3 干扰问题 94 车辆限速装置的应用 85 结语 9参考文献 10致谢 Error: Reference source not found汽车车速传感器检测系统设计摘 要汽车车速传感器设计是一种智能限速装置，利用速度传感器将转变成的电压信号输送给ECU（Electronic Control Unit），来控制速度，速度达到规定值时切断电路达到限速的目的。本文介绍了限速装置的工作原理，详细讲述了系统的组成、原理和测试方法。系统采纳硬件兼软件对测量过程及测量结果进行处理。与传统的限速装置相比，此限速器具有结构简单、新颖、易于实现的特点。实验证明在整个调速范围内都取得了良好的效果，系统具有良好的稳态精度及动态响应性能，同时也提高了限速装置的整体性能。关键词数据采集；控制装置；磁电式传感器；霍尔式传感器Design of vehicles speed limiting device AbstractOne kind of intelligent speedlimiting device is designed, using the speed sensor will change into a voltage signal transmission to the ECU (Electronic Control Unit), to control the speed of up to the required duty to cut off the circuit speed purposes. This paper introduced the working principle of speed device, described in detail the composition of the system, principles and testing methods. Hardware and software systems used to measure the process and measurement process. With the traditional speed devices compared to this overspeed governor is simple in structure, innovative, easy-to-implement features. Throughout the experiment proved that within the governor have made a good result, the system has a good steady performance of accuracy and dyn...
