精品文档---下载后可任意编辑毕业设计(论文)题 目专业名称指导老师指导老师职称班 级学 号 3学生姓名2024 年 4 月 23 日精品文档---下载后可任意编辑目 录 摘要ⅱ Abstractⅲ 绪论ⅳ1 八路无线抢答器的总体方案 11.1 八路无线抢答器的总体框图 21.2 八路无线抢答器的框图分析 222 抢答器原理 5抢答器简介 52.2 74ls14852.3 D 触发器 123 八路无线抢答器的无线通讯 173.1 无线接收模块 173.2 nRF905 简介 203.3 无线模块的选择 234 关于八路无线抢答器的自我认识 245 八路无线抢答器的总结 25总结 25参考文献 27致 谢 27精品文档---下载后可任意编辑摘 要这个设计将传统的有线抢答器改造成一种基于无线数传模块 NRF905 的八路抢答系统,系统由 1 台主机和 8 台子机组成,共占用 9 个无线频段,包括 1 个公共频段和 8 个子机频段。主机和子机均利用 AT89S52 单片机进行控制,实现抢答检测、成员分数显示和控制等功能。主机和子机之间的通信采纳 2 字节通信帧格式,并自定义通信命令与协议。并通过多种方式对抢答结果进行显示。关键词:无线;应答机;scmat89s52;检测;控制;通信 精品文档---下载后可任意编辑Abstract This design reforms the traditional wired answering device into a wireless data transmission module nRF905 Eight way responder system.The system consists of 1 hosts and 8 table machine.Occupies a total of 9 radio frequency band.Includes 1 public frequency band and 8 sub machine band.Host and promoter machine using AT89S52 MCU control, realize the violation detection alarm, timing, answer member scores display and control functions.The communication between host and promoter using 2 byte communication frame format, and custom communication command and protocol.The state of the different running states of vies to answer first division, using the time slice rotation system and state processing mechanism for different state for the processing and switching.Keywords : wireless; answering machine; scmAT89s52; detection;control;communication精品文档---下载后可任意编辑...
